Altronix HubSat8D Passive UTP Transceiver Hub with Integral Camera Power transmits UTP video, RS422/RS485 data and
power over a single CAT-5 or higher structured cable. Unit provides 8 camera channels in a wall mount enclosure. Video
transmission range is up to 750 ft. max. per channel. Units are compatible with AC and/or DC fixed or PTZ cameras when uti-
lizing Altronix HubWayAv, HubWayAv2, HubWayDv or HubWayDvi Video Balun/Combiners. In addition, the unit features
individually selectable 24VAC or 28VAC PTC protected outputs with surge suppression. Optionally, the HubSat8D can be
used as an accessory module to transmit video from up to 8 cameras over two (2) separate CAT-5 or higher structured cables
back to the HubWay, HubWayLD or HubWayLDH Passive and Active UTP Transceiver Hubs. In addition, the HubSat8D
provides power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs.
Agency Listings:
• UL Listed for Commercial CCTV Equipment (UL 2044).
CUL Listed - CSA Standard C22.2 No.1-04, Audio,
Video and Similar Equipment.
Input:
• 115VAC 60Hz, 2.5 amp.
• Primary in-line fuses are rated @ 3.5A/250V.
Video:
• Eight (8) channels of quality video over twisted pair
up to a distance of 750 ft. per channel.
• Eight (8) 75 ohm video outputs.
Data:
• RS422/RS485 data input.
Power:
• Individually selectable 24VAC or 28VAC power
outputs with OFF position.
HubSat82D
• HubSat8D with eight (8) HubWayAv
Video Balun/Combiners for 24VAC Cameras.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.
HubSat8D Passive UTP Transceiver Hub with Integral Camera Power.
1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure's
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install two fasteners. Place the enclosure's upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 8).
Secure green wire lead to earth ground.
2. Set illuminated master power disconnect circuit breaker to the [OFF] position (Fig. 4a, pg. 6).
3. Connect 115VAC 60Hz to the black and white flying leads of the open frame transformer. Secure ground
wire (Green) to earth ground (Fig. 4, pg. 6).
4. S elect 24VAC or 28VAC power output for each of the Channels 1-4 on HubSat Circuit Board A and
HubSat Circuit Board B (Fig. 4, pg. 6) with the corresponding output voltage switches. Select OFF position when
servicing or installing individual cameras (Fig. 1d, pg. 4).
5. Connect the BNC video outputs marked [Video 1-4] on Circuit Board A and [Video 1-4] on Circuit Board B to the
corresponding video inputs on the head end equipment (DVR) (Fig. 1a, pg. 4).
6. Connect terminals marked [+ Data - - - ] on Circuit Board A and Circuit Board B (polarity must be observed) to the
RS422/RS485 output of the head end equipment (DVR) (Fig. 1f, pg. 4).
Note: The Data input terminals of Circuit Board A and Circuit Board B must be wired in parallel
for proper operation. When using fixed cameras disregard this step.
- 2 -
Overview:
Specifica tions:
Power (cont.):
• Unit provides up to 1 amp max. per channel not to
exceed a total of 8 amp maximum current.
• PTC protected outputs are rated @ 1 amp per channel.
• Surge suppression.
Visual Indicators:
• Eight (8) power LED indicators.
Enclosure Dimensions (H x W x D approx.):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
Optional Accessories:
• Video Balun/Combiners:
- HubWayAv - for use with 24VAC cameras.
- HubWayAv2 - for use with 24VAC cameras.
- HubWayDv - for use with 12VDC cameras.
- HubWayDvi - for use with non-isolated 12VDC cameras.
Additional Models:
HubSat83D
• HubSat8D with eight (8) HubWayDv
Video Balun/Combiners for 12VDC Cameras.

Installation Instructions:

HubSat8D
