Passive UTP Transceiver Hub
with Integral Camera Power
Installation Guide
Models Include:
HubSat4WPV
- Four (4) Channel Outdoor Passive UTP Transceiver Hub with Integral Camera Power
HubSat42WPV
- Four (4) Channel Outdoor Passive UTP Transceiver includes four (4) HubWayAv
Video Balun/Combiners
HubSat43WPV
- Four (4) Channel Outdoor Passive UTP Transceiver includes four (4) HubWayDv
Video Balun/Combiners
Rev. 060210
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix HubSat4WPV
Summary of Contents for Altronix HubSat4WPV
-
Page 1: Installation Guide
Passive UTP Transceiver Hub with Integral Camera Power Installation Guide Models Include: HubSat4WPV - Four (4) Channel Outdoor Passive UTP Transceiver Hub with Integral Camera Power HubSat42WPV - Four (4) Channel Outdoor Passive UTP Transceiver includes four (4) HubWayAv Video Balun/Combiners... -
Page 2: Table Of Contents
HubSat4WPV Passive UTP Transceiver Hub with Integral Camera Power . . . . . . . . . . . . . . . . -
Page 3: Overview
(Green) to earth ground (Fig. 4, pg. 8) . 6 . S elect 24VAC or 28VAC power output for each of the Channels 1-4 on HubSat4WPV (Fig. 4, pg. 8) with the corresponding output voltage switches . Select OFF position when servicing or installing individual cameras (Fig. -
Page 4: Hubway/Hubwayld/Hubwayldh Utp Transceiver Hubs
9 . Plug the RJ45 connector at one end of the CAT-5 or higher structured cable into the RJ45 jack marked [PVD1] on HubSat4WPV (Fig. 2i, pg. 6) . Plug the RJ45 connector at the opposite end of the CAT-5 or higher structured cable into the RJ45 jack of the Video Balun/Combiner to be installed at camera 1 . -
Page 5: Alternate 24Vac Fixed Camera Hookup
9 . Set illuminated master power disconnect circuit breaker to the RESET (ON) position (Fig. 4a, pg. 8). 10 . The power LEDs (Green) of the HubSat4WPV will illuminate when AC power is present (Fig. 2e, pg. 6). Note: If any of the power LEDs are not illuminated the cause may be due to the following: a . -
Page 6: Hubsat Circuit Board
(DVR) . 2f - Data: 2i - Channels 1-4: RS422/RS485 input from head end equipment CAT-5 or higher structured cable to cameras . (DVR) for PTZ control . Pin out configuration (pg. 7). - 6 - HubSat4WPV... -
Page 7: Hubwayav, Hubwayav2, Hubwaydv, And Hubwaydvi Video Balun/Combiners
2 - Orange [VIDEO -- ] 3 - White/Green [DATA +] 4 - Blue [AC 1] 5 - White/Blue [AC 2] 6 - Green [DATA -- ] 7 - White/Brown [AC 2] 8 - Brown [AC 1] HubSat4WPV - 7 -... - Page 8 Fig. 4b Green Ground Wire Input 220VAC, 50/60Hz Fig. 4a - Illuminated master power disconnect circuit breaker: • OFF position: circuit breaker tripped – Switch not illuminated . • RESET (ON) position – Switch illuminated . - 8 - HubSat4WPV...
-
Page 9: Hubsat4Wpv Passive Utp Transceiver Hub With Integral Camera Power
Typical Application Drawing HubSat4WPV Passive UTP Transceiver Hub with Integral Camera Power: Fig. 5 Head End Equipment (DVR) Monitor RS485 Data Video Data Power Data CAT-5 Video HubWayAv Power CAT-5 Video Balun Combiner 24VAC PTZ HubWayDv/Dvi Camera Video Balun Combiner... -
Page 10: Wall Mount Installation
This installation should be made by qualified service personnel . This product contains no serviceable parts . PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures . Brackets are designed for use with the Wormgear Quick Release Straps (two included) . - Page 11 Notes: HubSat4WPV - 11 -...
-
Page 12: Enclosure Dimensions
Altronix is not responsible for any typographical errors . 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A . MEMBER...
