Altronix HubSat4DiV Passive UTP Transceiver Hub with Integral Isolated Camera Power transmits UTP video,
RS422/RS485 data and power over a single CAT-5 or higher structured cable . Unit provides 4 camera channels
in a wall mount enclosure . Video transmission range is up to 750 ft . max . per channel . Units are compatible
with AC and/or DC fixed or PTZ cameras when utilizing Altronix HubWayAv or HubWayDv Video Balun/
Combiners . In addition, the unit features individually selectable 24VAC or 28VAC electronically isolated PTC
protected outputs with surge suppression . Optionally, the HubSat4DiV can be used as an accessory module
to transmit video from up to 4 cameras over a single CAT-5 or higher structured cable back to the HubWay,
HubWayLD or HubWayLDH Passive and Active UTP Transceiver Hubs . In addition, the HubSat4DiV provides
power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs .
Input:
• 220VAC, 50/60Hz, 0 .75A .
Video:
• Four (4) channels of quality video over twisted pair
up to a distance of 750 ft . per channel .
• Four (4) 75 Ohm video outputs .
Data:
• RS422/RS485 data input .
Power:
• Individually selectable 24VAC or 28VAC power
outputs with OFF position .
• Unit provides up to 1A max . per channel not to
exceed a total of 4A maximum current .
• Individual electronically isolated outputs .
WARNING: To reduce the risk of fire or electric shock do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.

HubSat4DiV Passive UTP Transceiver Hub with Integral Isolated Camera Power.

1 . Mount unit in the desired location . Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure . Install two upper fasteners and screws in the wall with the screw heads protruding . Place
the enclosure's upper keyholes over the two upper screws; level and secure . Mark the position of the lower
two holes . Remove the enclosure . Drill the lower holes and install two fasteners . Place the enclosure's
upper keyholes over the two upper screws . Install the two lower screws and make sure to tighten all
screws (Enclosure Dimensions, pg. 12) . Secure green wire lead to earth ground .
2 . Set illuminated master power disconnect circuit breaker to the [OFF] position (Fig. 4a, pg. 8) .
3 . Connect unswitched AC circuit (220VAC, 60Hz) as follows: Green branch wire (ground) connects to
Input
the terminal marked
220VAC
marked [N] of the Inlet Appliance Connector (Fig. 5, pg. 9) . The power LEDs (Green) for Channels 1-4
of the HubSat4DiV will illuminate when AC power is present (Fig. 1e, pg. 6)
4 . S elect 24VAC or 28VAC power output for each of the Channels 1-4 on HubSat4DiV (Fig. 4, pg. 8) with the
corresponding output voltage switches . Select OFF position when servicing or installing individual cameras
(Fig. 1d, pg. 6) .
5 . Connect the BNC video outputs marked [Video 1-4] on HubSat4DiV to the corresponding video inputs on
the head end equipment (DVR) (Fig. 1a, pg. 6) .
6 . Connect terminals marked [+ Data –] on HubSat4DiV (polarity must be observed) to the RS422/RS485
output of the head end equipment (DVR) (Fig. 1f, pg. 6) . When using fixed cameras disregard this step .
7 . Plug the RJ45 connector at one end of the CAT-5 or higher structured cable into the RJ45 jack marked
[PVD1] on HubSat4DiV (Fig. 1i, pg. 6) . Plug the RJ45 connector at the opposite end of the CAT-5 or
higher structured cable into the RJ45 jack of the Video Balun/Combiner to be installed at camera 1 .
• For 24VAC cameras use Altronix model HubWayAv/HubWayAv2 Video Balun/Combiner
(Figs. 2a, 2b, 2e. pg. 7) .
• For 12VDC cameras use Altronix model HubWayDv Video Balun/Combiner (Figs. 2c, 2d, pg. 7) .
The total cable distance must not exceed 750 ft . for video transmission between the HubSat4DiV and each
camera . Repeat this step for all other camera channels [PVD2-4] .
HubSat4DiV
(ON)
28VAC
AUX1 AUX2
24VAC
VIDEO1 VIDEO2

Installation Instructions:

PVD1 PVD2 DATA 1-4
non power-
limited
, Line connects to the terminal marked [L], and Neutral connects to the terminal
60Hz

Overview:

Specifica tions:
Power (cont.):
• PTC protected outputs are rated @ 1A per channel .
• Surge suppression .
Visual Indicators:
• Four (4) power LED indicators .
Enclosure Dimensions (H x W x D):
8 .5" x 7 .5" x 3 .5" (215 .9mm x 190 .5mm x 88 .9mm) .
Optional Accessories:
• Video Balun/Combiners:
- HubWayAv - for use with 24VAC cameras .
- HubWayAv2 - for use with 24VAC cameras .
- HubWayDv - for use with 12VDC cameras .
28VAC 28VAC 28VAC
AUX3 AUX4
24VAC 24VAC 24VAC
VIDEO3
VIDEO 1-4 PVD3 PVD4
