Operation
①
⑭
⑬
⑫
⑪
⑩
Number
①
②
③
④
⑤
⑥
⑦
The Raynger 3i Plus series has three soft keys (F1, F2, and F3) just below the LCD display. There is a
"Soft Key Bar" on the LCD above the three soft keys to define their active function. By using soft keys,
the instrument has a convenient menu function. Each menu item and function is explained in detail in
the following sections.
In addition to the soft keys, there are also the <Save> and <Return> soft keys below the LCD display.
Selecting the <Menu> soft key advances the menu to the next level. The following table shows the top-
level description of the menu.
22
info@Raytek-Direct.com
②
Figure 5: User Interface
Description
Battery Symbol
Laser Indicator
Scan/Hold
Lock/Unlock
Low Temperature Alarm
High Temperature Alarm
Main Temperature Display
Table 2: Menu Overview
Rev. A1 Jan 2015
③ ④ ⑤
Number Description
⑧
Max. Value Display
⑨
Min. Value Display
⑩
Background Temp. Compensation
⑪
Transmissivity
⑫
Emissivity
⑬
"Hot" Warning Area
⑭
Bluetooth Symbol
⑥
⑦
⑧
⑨
3i Plus
