5.9 Save Button

The instrument can store up to multiple data records. The information below is stored in each record:
•
•
•
•
To save the current temperature reading (Basic test data):
1.
2.
3.
4.
The user can also push the <Cancel> soft key to not save the reading.
The <Save> soft key is also used to save records as profile or trend.

5.10 Menu

The instrument can display two languages, English and Simplified Chinese. To change the displayed
language, see section 5.10.10.6 Language, page 28.

5.10.1 Overview

There are many settings that can be changed with the menu. The following figure shows the LCD and
menu interface.
3i Plus
info@Raytek-Direct.com
down arrows to select each saved trend data. The user can then use left and right arrows to
view the three screens for each piece of trend data.
Profile test data: Profile setting under which 300 test data records (maximum) are saved.
Profile test data is defined as the test data under profile setting which could save maximum
300 records. By using the load value of each profile, these test data has been divided by group
according to the profile setting in PC software. User can find the temperature distribution
status in one group and convenient the measurement by using the setting in advance.
Record number
IR temperature in °F or °C
Date/Time
Emissivity
Pull the trigger to take a measurement.
Release the trigger to stop taking the measurement.
Push the <Save> soft key to enter the Save menu.
Push the <Yes> soft key to save the reading.
Rev. A1 Jan 2015
Operation
21
