- Page 1 User Manual TPC-1251T-Exxx TPC-1551T-Exxx Series TPC-1251H-Exxx TPC-1551H-Exxx Series Industrial Touch Panel Computers with ® Intel Atom™ Processors...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
-
Page 4: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 5: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 6 Caution! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dis- pose of used batteries according to the manufacturer's instructions. Attention! Danger d'explosion si la pile est remplacée de façon incor- recte.
-
Page 7: Table Of Contents
Chapter General Information ......1 Introduction ....................2 Specifications .................... 2 1.2.1 System Kernel................2 1.2.2 I/O Ports..................2 1.2.3 O/S support................... 2 1.2.4 Safety and Environment..............3 LCD Specifications..................3 Touchscreen Specifications ..............4 Power ......................4 I/O Ports Arrangement ................4 Figure 1.1 I/O Port Arrangement .......... - Page 8 EC Brightness Control Tool Installation ..........30 EC Watchdog Timer Driver Installation........... 32 Intel Graphics Driver Installation ............. 36 Intel Chipset Software Installation Utility Installation....... 39 Intel® Trusted Execution Engine Driver Installation........ 41 LAN Driver Installation ................44 Windows 7 USB 3.0 Driver Installation ........... 47 Touchscreen Driver Installation ..............
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Introduction The TPC-1251T/TPC-1551T & TPC-1251H/TPC-1551H Touch Panel Computers are state-of-the-art Human Machine Interfaces featuring 12" & 15" displays with Intel Atom™ E3827 1.75 GHz Processor The key features are as follows: True-flat touch screen TPC-xx51T series is true-flat touch screen designed with IP66 front protection (IP65 for traditional front bezel). -
Page 11: Safety And Environment
1.2.4 Safety and Environment Safety FCC Class A CE certificated The front bezel is compliant with IP66 for true flat models and IP65 for the TPCs with the traditional front bezel Environment Operating Temperature: – -20 ~ 60°C (-4 ~ 140°F) Storage Temperature: ... -
Page 12: Touchscreen Specifications
Touchscreen Specifications Touch Type: 5- wire Resistive Base Glass Construction: Tempered glass Resolution: 1024 x 1024 Light Transmission: 80% ± 3% (Measured by BYK-Gardner) Controller: USB Interface Lifespan: 1 million touches at single point Note! Touchscreen ITO maybe crash duo to heavy usage . -
Page 13: Panel Mounting
Panel Mounting There is a rubber waterproof gasket on the AL front bezel. Make sure the water- proof gasket is in position before installing TPC into the panel opening. Install the TPC into the panel opening. Take the clamps and long screws from the accessory box. Hook the clamps to the holes around the four sides of the bezel. -
Page 14: Figure 1.2 Tpc-1251T/Tpc-1251H Dimensions
Figure 1.2 TPC-1251T/TPC-1251H Dimensions TPC-xx51T/H User Manual... -
Page 15: Figure 1.3 Tpc-1551T/Tpc-1551H Dimensions
Figure 1.3 TPC-1551T/TPC-1551H Dimensions TPC-xx51T/H User Manual... - Page 16 TPC-xx51T/H User Manual...
-
Page 17: Chapter 2 System Setup
Chapter System Setup... -
Page 18: System Setup
System Setup You can easily get TPC started by following the below steps. Unpack the TPC package. Check the packing list at the beginning of this manual to make sure all items have been included. Figure 2.1 Unpack the Package TPC-xx51T/H User Manual... -
Page 19: Figure 2.3 Power Connector And Power Lines
® Install a CFast card containing the operating system. Figure 2.2 Install CFast Memory Card (Mylar in accessory box can be attached to CFast card for easy extraction) Warning! It is suggested to turn OFF system power as you plug in or pull out the memory card, even though the CompactFlash memory is hot swappa- ble. -
Page 20: Installing The Drivers
The drivers and utilities used for the TPC-1251T, TPC-1551T, TPC- 1251H & TPC-1551H panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engi- neers for the latest information regarding drivers and utilities. -
Page 21: Transport And Unpacking
Transport and Unpacking When accepting a delivery, please check the packaging for visible transport damage and check the delivery for completeness by comparing it with your order. If you notice any shipping damage or inconsistencies between the contents and your order, please inform the responsible delivery service immediately. -
Page 22: Cabinet Installation And Earth Grounding Setup
Secure the clamp to the panel using the included screws Cabinet Installation and Earth Grounding setup Please follow the following steps to setup TPC-xx51T/TPC-xx51H series, and please pay attention that Ground pin of TPC-xx51T/TPC-xx51H series should be connected to earth ground. Under this circumstance, TPC-xx51T/TPC-xx51H series could have the best performance such as EMI immunity, ESD immunity, Surge immunity and also system isolation. - Page 23 System wiring Step A: Connect the cabinet to earth ground. Step B: Ensure that all cabinet has been grounded together. Step C: Connect the ground of the power supply to the cabinet. Step D: Connect the ground pin of TPC-xx51T/TPC-xx51H series to the cabinet. Step E: Connect the I/O to the controller if needed.
- Page 24 TPC-xx51T/H User Manual...
-
Page 25: Appendix A Serial Port Settings
Appendix Serial Port Settings... -
Page 26: Jumper, Dip Switch And Connector Location
Jumper, Dip switch and Connector location A.1.1 A.1.2 Bottom TPC-xx51T/H User Manual... -
Page 27: Jumper Setting And Description
Jumper setting and Description A.2.1 CMOS Clear Function (CN1) CMOS Clear Function Description This jumper is used to select CMOS Clear Enable/Disable Default (1-2) (2-3) Enable (Clear CMOS) (1-2) Disable (1-2) Disable (2-3) Enable (Clear CMOS) Switch Setting COM2 RS232/422/485 mode setting (SW2) COM2 RS232/422/485 mode setting Description This switch is used to select COM2 RS232/422/485 mode setting... -
Page 28: Termination Resistor Select (Sw3)
Bit 1,2,3,4,5,8,9 OFF RS485 Mode Bit 6,7,10 ON A.3.1 Termination Resistor Select (SW3) Termination Resistor Select This switch is used to select Termination Resistor (120 ohm) for long Description distance transmission or device matching. Default Bit1 & Bit2 (ISO_COM2_DATA+ & ISO_COM2_RX-) ISO_COM2_DATA+ Pin 1 ISO_COM2_RX-... -
Page 29: Sata Power Connector (Cn13)
A.4.2 SATA Power connector (CN13) 1655000453 WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI Signal Description +V3.3SATA SATA power output 3.3V/1A +V5SATA SATA power output 5V/1A +V12SATA SATA power output 12V/0.5A A.4.3 Mini PCIE slot (MINIPCIE) 1654002538 MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68N7H Supports PCI1.1, PCI1.2 Power Definition Signal Description... -
Page 30: Cfast Slot (Cn14)
A.4.4 CFast slot (CN14) 1653004849 CFast 24P 1.27mm 90D(M) SMD N7G24-A0B2RA-10-0HT- The host is connected to the CFast Card using a 7+17 pin connector Segment CFast Name Description SATA SGND Ground for signal integrity SATA Signal Pair A : TX+/- (Transmit) SATA SATA... -
Page 31: Lan Rj45 Connector (Cn7,Cn8)
A.4.6 LAN RJ45 connector (CN7,CN8) 1652002996 PHONE JACK RJ45 14P 90D(M) DIP RTA-195AAK1A RJ45 Pin Signal Description In BASE-T: Media Dependent Interface[0]: 1000BASE-T: In MDI configuration, MDI[0]+/- corre- MDI0+ sponds to BI_DA+/- and in MDI-X configuration MDI[0]+/- corresponds to BI_DB+/-. ... -
Page 32: Usb Connector (Cn10)
A.4.7 USB connector (CN10) 1654010199 USB Conn. 2.0+3.0 13P 90D(F) DIP UEA1112C-UHS6-4 Signal Description 1, 10 USB VBUS USB Power output ,USB2.0 5V/0.5A and USB3.0 5V/0.9A 2, 11 USB_P- USB2.0 date - 3, 12 USB_P+ USB2.0 date + 4,13 Ground for Power return SSRX- USB3.0 RX - SSRX+... -
Page 33: Com2 Rs232/422/485 Connector (Cn16)
A.4.9 COM2 RS232/422/485 connector (CN16) 1654000056 D-SUB Conn. 9P 90D(M) DIP 070241MR009S200ZU RS232 RS422 RS485 TPC-xx51T/H User Manual... - Page 34 TPC-xx51T/H User Manual...
-
Page 35: Driver Installation And Configuration
Appendix Driver Installation and Configuration... -
Page 36: Ec Driver Installation
EC Driver Installation Follow the steps below to install the EC drivers: Launch folder \\EC\V1.03.0001 Install AdvEC_V1.03.0001.exe Click Next TPC-xx51T/H User Manual... - Page 37 Click Install Click Finish Choose Yes, then click OK to restart TPC-xx51T/H User Manual...
-
Page 38: Ec Brightness Control Tool Installation
EC Brightness Control Tool Installation Note! The EC driver must be installed first Follow the steps below to install the EC brightness control tool: Launch folder \\EC Brightness\V1.01.0002 Install AdvECBrightness_V1.01.0002.exe Click Next TPC-xx51T/H User Manual... - Page 39 Click Install Click Finish Choose Yes, then click OK to restart TPC-xx51T/H User Manual...
-
Page 40: Ec Watchdog Timer Driver Installation
EC Watchdog Timer Driver Installation Note! The EC driver must be installed first Follow the steps below to install the EC Watchdog Timer driver: Launch folder \\WDT\V1.30.0001 Install AdvWDT_v1.30.0001.exe TPC-xx51T/H User Manual... - Page 41 Click Next Choose Advantech [EC]WDT, then click Next TPC-xx51T/H User Manual...
- Page 42 Click Install Click Finish TPC-xx51T/H User Manual...
- Page 43 Choose Yes, then click OK to restart TPC-xx51T/H User Manual...
-
Page 44: Intel Graphics Driver Installation
Intel Graphics Driver Installation Follow the steps below to install the Intel Graphics driver: Launch folder \\Graphics Driver\Intel EMGD win7 32 bit\ Install Setp.exe Click Next TPC-xx51T/H User Manual... - Page 45 Click Yes Click Next Click Install TPC-xx51T/H User Manual...
- Page 46 Click Next Choose Yes, then click Finish to restart TPC-xx51T/H User Manual...
-
Page 47: Intel Chipset Software Installation Utility Installation
Intel Chipset Software Installation Utility Installation Follow the steps below to install the Intel Chipset Software Installation Utility: Launch \\Intel Chipset Software Installation Utility\SetupChipset_10.0.13_PV Install SetupChipset.exe Click Next TPC-xx51T/H User Manual... - Page 48 Click Accept Click Install Click Finish TPC-xx51T/H User Manual...
-
Page 49: Intel® Trusted Execution Engine Driver Installation
® Intel Trusted Execution Engine Driver Installation Follow the steps below to install the Intel Trusted Execution Engine driver: Launch folder \\TXE\Intel TXE Firmware\Win7 Install kmdf-1.11-Win-6.1-x86.msu Click Yes TPC-xx51T/H User Manual... - Page 50 Click Restart Now, then the system will restart Launch folder \\TXE\TXE_Win7_8_8.1_1.1.0.1089 Install SetupTXE.exe TPC-xx51T/H User Manual...
- Page 51 Click Next Click Next Click Next TPC-xx51T/H User Manual...
-
Page 52: Lan Driver Installation
Choose Yes, then click Finish to restart. LAN Driver Installation Follow the steps below to install the LAN driver: Launch folder \\LAN\Win7 \Install_Win7_7077_11282013 Install setup.exe TPC-xx51T/H User Manual... - Page 53 Click Next Click Install TPC-xx51T/H User Manual...
- Page 54 Click Finish TPC-xx51T/H User Manual...
-
Page 55: Windows 7 Usb 3.0 Driver Installation
Windows 7 USB 3.0 Driver Installation Follow the steps below to install the Windows 7 USB 3.0 driver: Launch folder \\USB3\Win7\SetupUSB3_3.0.0.33 Install Setup.exe Click Next TPC-xx51T/H User Manual... - Page 56 Click Yes Click Next Click Next TPC-xx51T/H User Manual...
-
Page 57: Touchscreen Driver Installation
Choose Yes, then click Finish to restart Touchscreen Driver Installation Follow the steps below to install the touchscreen driver: Launch folder \\TS\PenMount Windows Universal Driver V2.4.1.320(WHQL) Install Setup.exe TPC-xx51T/H User Manual... - Page 58 Click Next Click I Agree Click Install TPC-xx51T/H User Manual...
- Page 59 Click Finish Click Finish TPC-xx51T/H User Manual...
-
Page 60: Touchscreen Calibration
B.10 Touchscreen Calibration Follow the steps below to install the touchscreen driver: Launch PenMount Control Panel tool Double click PenMount 6000 USB TPC-xx51T/H User Manual... - Page 61 Follow the process to calibration touch screen Click OK to finish calibration TPC-xx51T/H User Manual...
- Page 62 TPC-xx51T/H User Manual...
-
Page 63: Appendix C Windows 8.X Bios Setup
Appendix Windows 8.X BIOS Setup... -
Page 64: Windows 8.X Bios Setup
Windows 8.X BIOS Setup Entre BIOS setting menu then go to Advanced page for Miscellaneous Configuration Select OS Selection to Widows 8.X TPC-xx51T/H User Manual... - Page 65 TPC-xx51T/H User Manual...
- Page 66 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
