Marea- Marea Weekend ©>
99 range
Copyright Fiat Auto
16v
1. Disconnect the gear selector cable track rod
end, lift up the retaining fork shown in the
diagram, then position the assembly to the
side in the engine compartment.
2. Disconnect the accelerator cable.
3. Disconnect the bands illustrated in the dia-
gram, then remove the air intake hose.
4. Disconnect the vacuum pipe from the brake
servo.
5. Disconnect the connector shown in the
diagram from the injection/ignition control
unit and remove the earth lead from the
control unit support.
Engine
Removing- refitting
3
