8- Camera Installation

1. Prepare Camera for Mounting
Prior to mounting to the Camera, we recommend that the position and angles be preset in order to speed installation. These
settings can be fine-tuned once the Camera is mounted.
IMPORTANT NOTE: To avoid damaging the dome surface during installation, keep the dome surface away from
walls and other objects. DO NOT remove the protective film from the dome until after the camera is mounted and
the dome installed.
Microfiber or similar cloths can be abrasive, only use a dry eyeglasses cloth when cleaning the lens to avoid
damage that can blur the camera's image.
A. Open the camera by using the provided 3mm Allen key to remove the three screws on the dome cover.
B. Install the microSD Card (optional)
The microSD card slot is located inside the camera base under the lens assembly. The lens assembly may need to be
rotated in order for the card slot tobe accessible. Up to a 32 GB card can be installed.
C. Pre-adjust the camera's 3-axis angle so the lens points in the desired direction. The lens angle should not exceed 67˚
off the center axis.
Warning: The lens angle must not exceed 67˚ off the center axis to avoid IR reflection off of the dome
resulting in a halo effect in the camera image at night.
D. Loosely install the dome until the camera is ready to be installed in the desired location.
www.snapav.com Support: 866.838.5052
microSD Card Slot
