WPS-750-DOM-IP Installation Manual

3- Required Items for Installation

The following items are required during the installation of a Wirepath™ IP Camera. It is recommended that these items are prepared
in advance to ensure that the installation can be performed smoothly.

All Cameras to be installed in the system

Network Connection near the location of the Camera

Administrator rights to the computer that will be used to configure the Camera(s)
Router / Switch Details – Contact the network admin to obtain
o
Admin Rights – Required to setup the network and port forwarding for remote access.
o
o
Static IP to assign to the Camera
o
Default gateway
o
Subnet Mask
o
DNS Address

Installation Manual for all the Wirepath™ Surveillance IP Cameras being installed

CD-ROM supplied with the Camera

4- Package Contents

(1) WPS-750-DOM-IP Camera
(1) WPS-ACC-PWR Power Adapter
(1) Female to Female RJ45 Adapter
(1) 3mm Allen key
(3) Screws
(3) Wall Fasteners
(1) Spare Silica Pack
(1) Quick Start Guide
(1) CD-ROM containing documents and setup software
NOTE: A POWER SUPPLY IS NOT INCLUDED WITH THIS CAMERA. The PS-12DC-1A, WPS-PS multiple output power supply or
a Power over Ethernet (PoE) switch is recommended.

5- Optional Accessories

Wirepath™ Surveillance offers a wide range of accessories that provide power to the cameras, allow for various mounting options,
and make connection to the head end quick and easy.

5.1- Mounts


WPS-MNT-EXT-DOM Dome Camera Extension Mount
Use to extend the camera away from the ceiling, and to hide wires for locations where wires cannot be placed into the ceiling.

WPS-MNT-FLUSH-DOM Dome Camera Flush Mount
Use to mount the camera ceiling for flush clean appearance.

WPS-MNT-L-DOM-WH Dome Camera L Mount
Use when the dome is to be mounted away from the wall, and to hide wires for locations where wires cannot be placed into the
wall.

WPS-MNT-ARM-DOM-WH Dome Camera Arm Mount
Use when the dome is to be mounted away from the wall, and to hide wires for locations where wires cannot be placed into the
wall.
