Ip dome camera

Table of Contents

WPS-750-DOM-IP Installation Manual

6.3- Main Camera Interface

Note: The camera requires configuration before accessing for the first time. See sections

Initial Configuration

6.3.1- Accessing the Camera

Note: IE 8.0 or higher is required to access the camera; other browsers are not supported at this time.

Open the web browser, and enter the IP Address that was assigned to the camera. The address should include the port

number assigned to the camera. Note that access varies between local network and remote access through a DDNS.

Local Network Example:

Remote Access (DDNS) Example:

A window will open asking for a username and password.

Default Username and Password:

Username:

Password:

Recommendation: After initial setup of the Cameras, we recommend that the password be changed to avoid

unwanted access.

C. Install the ActiveX control if prompted to do so.

D. After installing the ActiveX the camera should be visible in the web browser, if the camera does not appear, verify the IP

address by using the IP Installer.

6.3.2- Recommendations for Best Performance

As the number of open browser windows or tabs increases, the risk of slowed response time to the cameras increases. We

recommend that open browser windows or tabs be limited to no more than 4 to avoid interruption in communications or reduced

response time with the cameras.

Due to the limited upload speeds set by ISP (Internet Service Provider) we recommend that Streaming 2 is selected when viewing the

cameras remotely (outside the local network) as the lower resolution provides better frame rates allowing for a smoother video

stream.

Pg. 12

before opening the browser.

admin

http://192.168.1.56:8056

http://JonesIPCamera.wirepathdns.com:8056

9-IP Installer Software

and

10-

Table of Contents
