Wirepath WPS-100-BUL-A-SL Installation Manual

SAFETY INSTRUCTIONS

This information is provided to ensure your safety and to
prevent physical or financial loss. Please read this document
carefully before installing and operating the camera.
1. Handle with care.
This camera is not designed to resist heavy impact. Use
caution when handling to avoid damage to sensitive internal
components.
2. Do not install the camera under extreme temperatures.
This camera only operates under temperature conditions
between 14˚F ~ 140˚F.
3. Do not mount the camera directly facing bright light
sources.
Exposing the camera to strong light over long periods of time
will damage the camera's sensor.
4. Do not supply voltage other than 12VDC.
Higher voltages will damage the camera's
electronic components.
5. Do not install the camera in environments with extreme
humidity.
Installing camera in environments with extreme humidity may
cause moisture to condense on the surface of the lens or
dome cover, which can affect picture quality.
FEATURES
• 1/4" Sony Sharp Color CCD
The Sharp CCD offers low Lux capatability with a clear,
crisp image.
• Fixed Lens
This camera features a wide-angle lens with a focal length
of 3.6mm for a wide range of applications.
• Built-In Infrared
IR LEDs provide the ability to capture images during night
and low light conditions.
• Backlight Compensation
Backlight compensation will adjust the exposure of a
subject standing in front of a bright light source.
© 2012 Wirepath Surveillance
WPS-100-BUL-A-SL
BULLET
CAMERA
WPS-100-BUL-A-SL Installation Manual
INSTALLATION MANUAL
Review manual thoroughly
before installation.
Retain for future reference.

PACKAGE CONTENTS

(1) Camera
(1) DC Plug
(3) Screws
(3) Wall fasteners
(1) Foam Gasket
Manual
NOTE: A POWER SUPPLY IS NOT INCLUDED WITH THIS CAMERA.
The PS-12DC-1A is recommended.

SPECIFICATIONS

WPS-100-BUL-A-SL Wirepath™ Surveillance IR Outdoor Bullet
Camera with Fixed Lens (420 TVL)
Image Sensor
Number of Pixels
Lens
Shutter Control
Auto Electronic Shutter
Auto Gain Control
Back Light Compensation ON
Auto White Balance
Sync. Mode
Scanning System
Resolution
S/N Ratio
Gamma
Minimum illumination
IR Range
Horizontal Sync.
Frequency
Video Output
Power Source
Power Consumption
Operating Temperature
Certifications
Weatherproof
Dimensions
Net Weight
1/4" Sharp CCD
NTSC:768(H)x494(V) PAL:752(H)
x582(V)
3.6mm Fixed, Horizonal FOV 50˚
<NTSC>1/60~1/100,000 sec;
<PAL>1/50~1/100,000 sec
ON
ON
ON
Internal Sync
2:1 Interlace
420 TV Lines
>48dB
0.45
.3 Lux color, 0 Lux IR on
32ft
NTSC: 15.734KHz; PAL: 15.625KHz
1.0Vp-p,75ohm
12 VDC (500 mA) – Not included
3.6W - 300mA
14F-140F
CE, FCC, ROHS
IP54 Grade
6.25 (L) x 5 (H) with sun shade
and bracket fully extended
.49 lb
*Specifications are subject to change without notice
