WPS-565-BUL-A Installation Manual Safety Instructions This information is provided to ensure your safety and to prevent physical or fi nancial loss. Please read this document carefully before installing and operating the camera. 1. Handle with care. Use caution when handling to avoid damage to sensitive internal components.
WPS-565-BUL-A Installation Manual Table of Contents 1. Features 2. Package Contents 3. Wiring Recommendations 3.1. Wiring Connections 4. Installation Instructions 5. Camera Operation Setup 5.1. Focus, Zoom and Position 5.2. Using the Test Adapter 6. OSD SETUP Menu 6.1. Default Settings Description 6.2.
Page 4
WPS-565-BUL-A Installation Manual 6.4.6. DPC (Dead Pixel Compensation) 6.4.7. SPECIAL Menus 6.4.7.1. CAM TITLE Setting 6.4.7.2. MOTION Detection 6.4.7.3. PRIVACY Setting 6.4.7.4. PARK LINE Setting 6.4.7.5. IMAGE ADJ. Setting 6.4.7.6. COMM ADJ. — RS485 Setup 6.4.8. Exit Menu — Save and Reset 6.4.8.1.
WPS-565-BUL-A Installation Manual 1. Features 1/3” 960H Sony Super-HAD II CCD The Sony Super HAD II CCD is ideal for low lux illumination, resulting in a clear and crisp image. Varifocal Auto-Iris Lens This camera features a varifocal lens with a focal length of 2.8-12 mm. The auto- iris function intuitively manages the amount of light passing through the lens for consistent image brightness.
WPS-565-BUL-A Installation Manual 2. Package Contents (1) WPS-565-BUL-A Camera (1) WPS-ACC-PWR-M AC/DC Power Plug (1) OSD Joystick / BNC Test Adapter (4) Surface Mounting Screws (includes 1 spare) (4) Wall Anchors (includes 1 spare) (1) 3mm Allen key (1) Installation Manual (1) Spare Silica packet in vacuum sealed bag NOTE: A POWER SUPPLY IS NOT INCLUDED WITH THIS CAMERA.
75-ohm rated BNC connectors RG-59 or RG-6 Use a BNC-RCA adapter for composite input 3. RS485 Communication +/- Wires (Optional) Connect the RS485 wires to a controller or a Wirepath DVR for remote access to the OSD setup menu. Pinout Wire Size (AWG)
WPS-565-BUL-A Installation Manual 4. Installation Instructions Wiring must be installed before the camera. See the previous page for connections and wiring recommendations. Step 1. Prepare for Installation A. Unpack the camera and locate the included hardware, silica packet, and 3mm Allen wrench. If a mounting accessory is being used, unpack the acces- sory and become familiar with its installation and use.
Page 9
WPS-565-BUL-A Installation Manual Step 3. Position the Camera Adjust the camera to point in the proper direction using adjustment points A, B, and C. Use the 3mm Allen wrench to loosen and tighten each adjustment screw. A. Horizontal rotation B. Swivel left or right C.
WPS-565-BUL-A Installation Manual 5. Camera Operation Setup 5.1. Focus, Zoom and Position The lens of the camera has manual focus and zooms knobs for setting the correct field of view. Connect the test adapter as described below to use a monitor at the camera location for viewing adjustments.
WPS-565-BUL-A Installation Manual 6. OSD SETUP Menu WPS-565 series cameras use an on-screen (OSD) menu system for setup of advanced image and control settings. SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY&NIGHT SPECIAL EXIT SAVE Default OSD menu view and settings Use the OSD SETUP menu to: •...
WPS-565-BUL-A Installation Manual 6.2. How to Navigate the OSD SETUP Menu The OSD menu is displayed as an overlay of the camera field-of-view. It will remain visible as long as the menu is active. Use the test adapter or RS485 to navigate.
Page 14
WPS-565-BUL-A Installation Manual CAM TITLE (all 4 are on by default) AREA SEL. AREA STATE HEIGHT 0...3...15 MOTION WIDTH 0...3...15 LEFT/RIGHT 0...2...15 TOP/BOTTOM 0...2...15 DEGREE 0...32...255 VIEW (all 8 are on by default) AREA SELECT AREA STATE HEIGHT 0...255 (default setting varies for each of the 8 areas)
WPS-565-BUL-A Installation Manual 6.4. OSD MENU SETTINGS 6.4.1. LENS Menu The amount of light entering the camera lens is controlled by the size of the aperture, (called IRIS in SETUP menu). SETUP LENS • The default DC setting is recommended when lighting levels vary regularly.
WPS-565-BUL-A Installation Manual 6.4.2. EXPOSURE Menu Exposure settings use the sensor in the camera to control how much light is recorded in each frame of video. EXPOSURE SHUTTER AUTO MIDDLE DWDR RETURN • Access the EXPOSURE sub-menu settings from the main SETUP menu.
WPS-565-BUL-A Installation Manual 6.4.3. WHITE BALANCE Menu White balance adjusts the image color according to the lighting conditions of the scene to correct for different lighting color ranges. SETUP WHITE BAL • Move the joystick left or right to select the desired mode.
WPS-565-BUL-A Installation Manual 6.4.4. BACKLIGHT Menu Back Light Compensation (BLC, default) clarifies objects in front of bright light. For example, in a scene with lighting facing the camera, if a person walks toward a normal camera, they will appear as a silhouette, but BLC will adjust contrast for more detail.
WPS-565-BUL-A Installation Manual 6.4.5. DAY & NIGHT Menu The camera sensor has DAY (color) and NIGHT(black and white) mode. Use this menu to set up the mode, how it is switched and also IR levels. • Move the joystick left or right to select a mode and enter its sub-menu (if applicable).
WPS-565-BUL-A Installation Manual 6.4.6. DPC (Dead Pixel Compensation) Dead Pixel Compensation automatically removes defective pixels and “fills in” the image. Use the UP arrow function to exit this menu without performing DPC. DPC VIEW LS VALUE | | | | | | | | | | | | | | | DIFF.
WPS-565-BUL-A Installation Manual 6.4.7. SPECIAL Menus 6.4.7.1. CAM TITLE Setting The CAM TITLE sub-menu provides the ability to set a camera name and have it appear on the screen. • CAM TITLE — Set to ON to display the camera name on the screen.
WPS-565-BUL-A Installation Manual 6.4.7.3. PRIVACY Setting Privacy Mask allows the masking of up to 8 “surveillance-free” zones in the field of view. This may be used for a camera that has a neighbor’s window in part of the scene, or with an area where sensitive information would be visible.
RS-485 communication. • PROTOCOL — Scroll left or right to select a communication protocol - PELCO-D or PELCO-P. Wirepath devices use Pelco-D. • DISPLAY ID — Scroll left or right to set DISPLAY ID to ON and show the CAMERA ID on the screen.
WPS-565-BUL-A Installation Manual 7. Troubleshooting If you have trouble operating the camera, first refer to the following guidelines. If the problem persists, contact Technical Support at (866) 838-5052. Nothing appears on the display: • Check if the power for the camera and the monitor is ON.
This warranty shall not apply to products which have been abused, modified, disassembled or improperly installed. Products to be repaired under this warranty must be returned to Wirepath™ Surveillance or a designated service center with prior notification and an assigned return authorization number (RA).
