- Page 1 WPS-365-BUL-A BULLET CAMERA INSTALLATION MANUAL Review manual thoroughly before installation. Retain for future reference.
-
Page 2: Table Of Contents
WPS-365-BUL-A Installation Manual CONTENTS Safety Instructions ..................3 Features ......................4 Package Contents ..................4 Installation Instructions ................5 Troubleshooting ..................8 Specifications .....................9 Dimensions ....................10 Warranty .....................11 Contacting Technical Support ..............11... -
Page 3: Safety Instructions
WPS-365-BUL-A Installation Manual SAFETY INSTRUCTIONS This information is provided to ensure your safety and to prevent physical or financial loss. Please read this document carefully before installing and operating the camera. 1. Handle with care. This camera is not designed to resist heavy impact. Use caution when handling to avoid damage to sensitive internal components. -
Page 4: Features
WPS-365-BUL-A Installation Manual FEATURES • 960H 1/3” Sony Super-HAD II CCD The 960H Sony Super HAD II CCD is ideal for low lux illumination, resulting in a clear and crisp image. • Varifocal Auto-Iris Lens This camera features a varifocal lens with a focal length of 2.8~12 mm. The auto-iris function intuitively manages the amount of light passing through the lens for consistent image brightness. -
Page 5: Installation Instructions
WPS-365-BUL-A Installation Manual INSTALLATION INSTRUCTIONS Step 1. Prepare Camera for Mounting Prior to mounting the camera, take into account the angle-of-view limits. Ensure that the bullet camera can be aimed toward the desired field of view. A. Adjust camera rotation B. - Page 6 WPS-365-BUL-A Installation Manual Step 3. Mount the Camera A. Mounting directly to a wall or eve:Use the camera base as a template to mark screw locations. A.1. Pre-drill holes in the marked locations. A.2. Connect the wires from the wall to the camera’s pigtail and insert them into wall.
- Page 7 WPS-365-BUL-A Installation Manual Step 4. Fine-Tuning Camera Adjustments The camera is supplied with a BNC test adapter that plugs into the camera test port. This allows for viewing the output of the camera on a monitor or the WPS-CCTV-TESTER (not included). Use this connection to view and adjust the camera’s positioning, zoom, and focus directly from...
-
Page 8: Troubleshooting
WPS-365-BUL-A Installation Manual TROUBLESHOOTING If you have trouble operating the camera, first refer to the following guidelines. If the problem persists, contact Technical Support at (866) 838-5052. Nothing appears on the display: • Check if the power for the camera and the monitor is ON. -
Page 9: Specifications
WPS-365-BUL-A Installation Manual SPECIFICATIONS Imaging Image Sensor 960H 1/3" Color Sony Super HAD II Lens 2.8 ~ 12mm Varifocal Auto Iris Lens Estimated Horizontal Viewing Angle 92˚(W) ~ 30˚(T) Resolution (TVLs) 650 TV Lines Effective Pixels NTSC: 976(H)x494(V) Gamma 0.45 S/N Ratio >50dB... -
Page 10: Dimensions
WPS-365-BUL-A Installation Manual DIMENSIONS 9.07in. 8.39in. 3.4in. 3.82in. 3.2in. 0.6in. Ø 3.06in. -
Page 11: Warranty
Products to be repaired under this warranty must be returned to Wirepath™ Surveillance or a designated service center with prior notification and an assigned return authorization number (RA). CONTACTING TECHNICAL SUPPORT Phone: (866) 838-5052 Email: support@snapav.com... - Page 12 © 2014 Wirepath Surveillance 140410-1143...
