- Page 1 WPS-550-BUL-IP IP BULLET CAMERA INSTALLATION MANUAL Review manual thoroughly before installation. Retain for future reference.
-
Page 2: Safety Instructions
WPS-550-BUL-IP Installation Manual 1. Safety Instructions Read and follow all instructions and warnings in this manual. Keep for future reference. Install according to manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. -
Page 3: Table Of Contents
8.1. First Time Access Instructions 8.1.1. Recommendations for Best Web Viewing Performance 8.2. Camera Web Browser Interface 8.2.1. Web Interface Layout - Top Bar 8.2.2. Web Interface Layout - Bottom Bar 9. Camera Configuration Menu Setup © 2014 Wirepath Surveillance... -
Page 4: Streaming
WPS-550-BUL-IP Installation Manual 9.1. Configuration Menu - Access and Navigation 9.1.1. Accessing the Menu 9.1.2. Configuration Menu Layout 9.1.3. Configuration Menu Guidelines 9.2. System Information and Settings 9.2.1. System Information Menu Settings 9.2.1.1. Server Information 9.2.1.2. OSD Setting 9.2.1.3. Time Setting 9.2.1.4. - Page 5 9.5. Event Record Setup and Scheduling 9.5.1. Event Settings Menu 9.5.1.1. Record File 9.5.1.2. Record Time Setting 9.5.1.3. Network Disconnected 9.5.1.4. Network IP Check 9.5.2. Configuring Motion Detection Areas 9.5.2.1. Motion Detection Settings Overview 9.5.2.2. Adding a New Motion Detection Area © 2014 Wirepath Surveillance...
- Page 6 WPS-550-BUL-IP Installation Manual 9.5.2.3. Removing a Motion Detection Area 9.5.3. Schedule Menu 9.5.3.1. Snapshot Menu 9.5.3.2. How to Set Up Scheduling for Events 9.5.3.3. Set Up Snapshot 9.6. Log List 9.6.3.1. System Log 9.6.3.2. Motion Detection Log 9.6.3.3. All Logs 9.7.
-
Page 7: Introduction
WPS-550-BUL-IP Installation Manual 2. Introduction Thank you for purchasing a Wirepath™ IP Surveillance camera. The WPS-550-BUL-IP is an indoor/outdoor camera designed for mounting to any wall, ceiling or surface, for easy monitoring over a web or smartphone interface. We recommend that this document be read in its entirety before proceeding with system design, installation, or operation of the camera. -
Page 8: Package Contents
Power over Ethernet (PoE) switch is recommended. 4. Required Items for Installation The following items are required during the installation of a Wirepath™ IP camera. Prepare all parts and tools in advance to ensure that the installation can be performed smoothly. -
Page 9: How It Works
How Does IP Video Surveillance Work? Wirepath™ IP cameras use a digital image processor to capture video in a stream of packets that are broadcast using a standard Ethernet network. These packets can be received by several devices at once, including local PCs, mobile devices, and recorders (NVRs) on the same network, or even off the network (with the correct setup and web access). -
Page 10: Camera Connections
6. Camera Connections Wirepath™ Surveillance IP Cameras can be powered by Power over Ethernet (PoE) through the Cat5e/Cat6 Ethernet connection. This method is recommended because it limits the amount of wiring required, reducing installation cost and time. The camera must be connected to a compatible PoE-equipped router/switch or a PoE injector for this method to work. -
Page 11: Camera Installation Instructions
Remove the spare silica packet from its sealed foil package (taking care not to rip the inner packet) and place it inside the test adapter opening. C. Close the cap, and make sure the cap is sealed securely. © 2014 Wirepath Surveillance... -
Page 12: Network Software Setup - Ip Installer
7.7. Network Software Setup - IP Installer The IP Installer software included with the camera provides a quick view of Wirepath™ IP Surveillance devices connected to the local network. Use the Installer to search for and set basic IP settings for each camera. -
Page 13: Ip Installer-Configuring Camera Ip Settings
Once the IP address has been set, the camera can be accessed through the web browser. Note that on initial access to each camera, Active X controls will need to be installed on each PC that is used to access the camera. Continue to the next section for web browser access and setup. © 2014 Wirepath Surveillance... -
Page 14: Ip Camera Web Interface - Setup And Use
WPS-550-BUL-IP Installation Manual 8. IP Camera Web Interface - Setup and Use 8.1. First Time Access Instructions Connect the PC to the same local network (LAN) the camera is connected to. Open the web browser and enter the IP address that was assigned to the camera. The address should include the port number assigned to the camera if one was set. -
Page 15: Camera Web Browser Interface
Takes a JPEG snapshot of the current image that can be saved to the PC or a network drive. Config Click to enter the Configuration menus. All network and camera settings are configured in this menu. You must be logged in with administrator privileges to access the Configuration Menu. © 2014 Wirepath Surveillance... -
Page 16: Web Interface Layout - Bottom Bar
WPS-550-BUL-IP Installation Manual 8.2.2. Web Interface Layout - Bottom Bar Information Bar Displays basic information about the camera feed. Video Size Adjusts the size of the Live View area within the browser window. Video Source (If Streaming 2 is enabled) Allows for selection of one of two video streams from the camera. -
Page 17: Camera Configuration Menu Setup
Navigating away from pages with an “Apply” button without saving will cause settings to revert. Be sure to scroll down to the bottom of any menu before navigating away to check for an option to apply the setting, or refer to the manual. © 2014 Wirepath Surveillance... -
Page 18: System Information And Settings
WPS-550-BUL-IP Installation Manual 9.2. System Information and Settings 9.2.1. System Information Menu Settings • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner. 9.2.1.1. Server Information MAC Address Cannot be changed. Use the MAC address to identify a camera if IP settings have been lost. Server Name Modify the name given to the camera during IP Installer Setup. -
Page 19: Time Setting
Network LED Enable or disable the network status lights on the RJ45 connector (back of the camera) The LEDs are useful for setup and diagnostics, but may cause unwanted color reflections behind the camera during regular use. © 2014 Wirepath Surveillance... -
Page 20: Camera Time Setup
WPS-550-BUL-IP Installation Manual 9.2.2. Camera Time Setup Important! Wirepath™ Surveillance strongly recommends using the “NTP” time setting option unless Internet access is not available from the camera network. Other settings may not keep the correct time after power outages or other failures. -
Page 21: Ntp Setup Instructions (For Cameras With Internet Access)
9.2.2.2. Synchronize With PC’s Time). This will reset the camera time each time it is accessed. The PC will be much more likely to have accurate settings, since it also connects to other networks and the Internet. © 2014 Wirepath Surveillance... -
Page 22: User Management
WPS-550-BUL-IP Installation Manual 9.2.3. User Management • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “User Management” in left column “System” sub-menu. 9.2.3.1. Anonymous User Login Enabling this feature allows anyone that visits the address of the camera to: •... -
Page 23: Administrator Account Setup
After a Guest Account has been created, the password may be changed by clicking the “Edit” button in the User List. To change the username, a new account must be created and the old one removed. © 2014 Wirepath Surveillance... -
Page 24: System Update
WPS-550-BUL-IP Installation Manual 9.2.4. System Update • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “User Management” in left column “System” sub-menu. Important! Updating Firmware MUST be performed over a wired IP connection to the device to ensure that a connection is sustained throughout the process. -
Page 25: How To Back Up Camera Settings
C. Click the Apply button below the Browse button on the right. D. The camera will be updated with the settings in the file. After the update, it may be necessary to log into the camera again to regain access. © 2014 Wirepath Surveillance... -
Page 26: Upgrade The Firmware
WPS-550-BUL-IP Installation Manual 9.2.4.6. Upgrade the Firmware Important! Updating Firmware MUST be performed over a wired IP connection to the device to ensure that a connection is sustained throughout the process. If connection is lost during update, use the IP Installer to find the device again and restart the update. -
Page 27: Network Ip Settings
(Optional by network) Second Domain Name Server for the camera network. (Found in the router) DNS 1 If no secondary DNS is set, use 0.0.0.0 Click “Apply” at the bottom right of the page to save modified settings. © 2014 Wirepath Surveillance... -
Page 28: Port Assignment
WPS-550-BUL-IP Installation Manual Basic IP Settings, Continued 9.3.1.2. Port Assignment Port for accessing the camera web interface. Set to 80 by default. Each Camera must have a unique Web Page port number in order to access from outside the local network. To make port numbering easy to Port remember, use 4 digits: “8”... -
Page 29: Rtsp Setting
RTSP allows direct control of the stream from within the camera. This technology enables Wirepath™ products to stream video to devices even if they can’t support any of our remote viewing apps. Leave RTSP disabled if it will not be used. -
Page 30: Onvif
ONVIF The ONVIF (Open Network Video Interface Forum) standard is used by IP surveillance for communication across devices from various manufacturers. This setting does not require configuration when being used with Wirepath™ IP surveillance devices. ONVIF Select the desired ONVIF standard to be used in the camera, or disable the feature. -
Page 31: Advanced Ip Settings - Https Access Setup
To use this feature, a certificate must be created and then verified by a third party. To set up HTTPS access correctly, contact the HTTPS verifier. Note: Wirepath™ Surveillance does not provide HTTPS certificates. • Navigation: Log in as an administrator. From Home Screen, click “Config” button in top right corner, then click “Advanced” in left column, then click “ONVIF”... -
Page 32: Advanced Ip Settings - Snmp
WPS-550-BUL-IP Installation Manual 9.3.3. Advanced IP Settings - SNMP SNMP (Simple Network Management Protocol) is used for network management of larger networks. It allows for monitoring network devices such as IP cameras via a management host. This is an advanced setting that should be used only on larger systems. Configuration requires consulting with the network administrator. -
Page 33: Advanced Ip Settings - Access List (Ip Filter)
IP Address... 9.3.4.3. Controlling Administrator Access for instructions. Admin IP Enter the address the Administrator will access the camera from. Address Click “Apply” at the bottom right of the page to save Administrator IP Address access settings. © 2014 Wirepath Surveillance... -
Page 34: Add Or Remove Ip Addresses Or Ranges
WPS-550-BUL-IP Installation Manual 9.3.4.2. Add or Remove IP Addresses or Ranges Enable IP Address Filtering to gain access to the settings: Enter an IP address or range of addresses into the field and select whether to allow or deny access: Single IP Address: IP Address Range: C. -
Page 35: Advanced Ip Settings - Qos/Dscp
Enter a DSCP value between 0 and 63 to use when event/alarm traffic is being sent across the network. Management Enter a DSCP value between 0 and 63 to use when management traffic is being sent across the network. Click “Apply” at the bottom right of the page to save modified settings. © 2014 Wirepath Surveillance... -
Page 36: Pppoe Setup
WPS-550-BUL-IP Installation Manual 9.3.6. PPPoE Setup 9.3.6.1. PPPoE Overview Point-to-Point Protocol Over Ethernet (PPPoE) is a network protocol primarily used with DSL (Digital Subscriber Line) providers and modems. This protocol requires a login to connect to the modem even when a router is used. Configuration of these settings is not required to operate the camera on a standard network. -
Page 37: Ddns Setup
9.3.7.4. Setting Up a DDNS Address – WirepathDNS) Our free Wirepath™ DNS service is fast to set up right through the camera interface – no PC required – and it provides maximum uptime thanks to redundant USA-based servers located across the country. -
Page 38: Setting Up A Ddns Address - Wirepathdns
9.3.7.4. Setting Up a DDNS Address – WirepathDNS To use Wirepath DDNS service, enable the DDNS feature by selecting the button. Enter a prefix for the address in the host name field as shown in the example above (system1). C. Click “Apply” in the bottom right corner to save the address. After a moment, the page will reload and the address will appear in the “State”... -
Page 39: Server Settings
Check the box to enable a secure connection when sending emails. This is required for most SMTP Connect servers. Test Click Test to send a test email to all receivers and Bcc mail addresses when setting up notifications. Click “Apply” at the bottom right of the page to save modified settings. © 2014 Wirepath Surveillance... -
Page 40: Ftp Settings
WPS-550-BUL-IP Installation Manual 9.3.8.3. FTP Settings An FTP server is a remote computer server the camera connects to over the network or Internet. When an FTP server is configured, recorded video and snapshot files can be stored on the server for later access. Contact the network administrator for FTP server setup information. -
Page 41: Network Share Settings
Test Click the Test button to send a file to the Network Share server. Use Test to confirm that new settings are correct. Click “Apply” at the bottom right of the page to save modified settings. © 2014 Wirepath Surveillance... -
Page 42: Camera A/V Settings
WPS-550-BUL-IP Installation Manual 9.4. Camera A/V Settings 9.4.1. Image Settings Menu The image setting menu is used to set up the camera view for the best image possible. Brief descriptions of the menu are given below. Complete instructions for setup are in the following sections. •... -
Page 43: Tips For Getting The Best Camera Image
Use the Image Settings to adjust the picture. See section 9.4.1. Image (Night) Settings Menu for setup instructions Forces camera to switch between Color and B&W modes at specific times. See section 9.4.2.3. Time Time Mode Mode Setup for setup instructions. © 2014 Wirepath Surveillance... -
Page 44: Ext Light Sensor Mode (Default Mode)
WPS-550-BUL-IP Installation Manual 9.4.2.2. EXT Light Sensor Mode (Default Mode) The default day-night settings are usually ideal. The camera has been calibrated to run in color mode as long as enough ambient light is available for the sensor to use. Once the scene begins to darken, the camera will adjust to black and white night mode, and the IR LEDs will turn on as needed. -
Page 45: How To Configure Privacy Masks
B. Removing a Privacy Mask Select the button for the area to remove. The colored grid for the selected area will be removed. Select Save to save the change. The black privacy mask will be removed. © 2014 Wirepath Surveillance... -
Page 46: Video Settings Menu Overview
External factors like network traffic or a slow Internet connection limit the quality. Stream 2 can be set to output a different stream type (H.264 or MJPEG) or to a lower quality setting. If a camera is accessed by a Wirepath™ NVR, Stream 2 will be forced open so that recording takes place. -
Page 47: Video Streaming 1 And 2 Setup
Quantitative or decrease depending on the select option. This setting will change if the camera is enabled or modified from a Wirepath™ NVR, since the NVR requires a CBR stream. (Advanced Mode Only) Sets the fixed bitrate to use when CBR is selected for bitrate control. The recommend Video Bitrate setting is 1, 2, 4, 6 or 8 Mbps for compatibility with Wirepath NVRs. -
Page 48: Streaming 3 And 4 Setup
WPS-550-BUL-IP Installation Manual Video Streaming 1 and 2 Setup, Continued GOP (Group of Pictures) is used to generate the visible frames of a video stream. The GOP size setting determines the multiplier to use for producing intermediate frames based on a standard of 15fps. Example: 1/2xFPS=7.5fps 1xFPS=15fps 2xFPS=30fps... -
Page 49: Event Record Setup And Scheduling
Detection may be may also be toggled on and off by scheduling. Motion detection settings are detailed in a separate section: 9.5.2. Configuring Motion Detection Areas. Continue to the next page for other menu descriptions. © 2014 Wirepath Surveillance... -
Page 50: Record File
WPS-550-BUL-IP Installation Manual 9.5.1.1. Record File Selects the file type to create when the event occurs: • AVI File – Creates a short .AVI format video file. • JPEG Files (Streaming 1 must be set MJPEG) – Creates a series of JPEG files at about 1fps. •... -
Page 51: Configuring Motion Detection Areas
Only in Schedule When selected, motion events will only be triggered based on a configured schedule. Times Click “Apply” at the bottom right of the page to save modified settings. © 2014 Wirepath Surveillance... -
Page 52: Adding A New Motion Detection Area
WPS-550-BUL-IP Installation Manual 9.5.2.2. Adding a New Motion Detection Area Select Event Setting under Event on the left side Menu. Select the Area for Motion Detection. C. Select Area 1 next to the blue box. D. Place the mouse at the upper left-hand corner of the area to mask, hold down the left mouse button and drag the box over the area to mask and release the mouse button. -
Page 53: Schedule Menu
Enter a name to use to identify the snapshot files. Use this menu to configure the Cameras Contact & File Name Relay connections. Click “Apply” at the bottom right of the page to save modified settings. © 2014 Wirepath Surveillance... -
Page 54: How To Set Up Scheduling For Events
WPS-550-BUL-IP Installation Manual 9.5.3.2. How to Set Up Scheduling for Events Select Schedule under Event on the left side Menu. Select the Enabled check box. C. Click on the box(es) to enable one-hour blocks of time for the desired Day of week and Time of day. 9.5.3.3. -
Page 55: Log List
Click “Logs” to open and view the log file in a new browser window. 9.6.3.3. All Logs Displays a list of all log entries from the three individual logs. Click “Logs” to open and view the log file in a new browser window. © 2014 Wirepath Surveillance... -
Page 56: Sd Card Menu
WPS-550-BUL-IP Installation Manual 9.7. SD Card Menu Use this menu to set up and access a microSD card. 9.7.1. Playback This area will display “No SD Card” when no microSD card is installed. When a compatible card is installed and the card contains media, folder names are displayed using the dates when media was saved as titles. -
Page 57: Reset Procedure
Use your computer, or iPhone ® , native iPad ® , or Android ® smartphone apps to view cameras while at the office or on the go. Details on setup and operation can be found at www.SnapAV.com. © 2014 Wirepath Surveillance... -
Page 58: Specifications
WPS-550-BUL-IP Installation Manual 13. Specifications Imaging Image sensor 1/2.7” 1MP CMOS sensor Lens Type 2.8mm Mega Pixel Fixed Lens F1.8 View Angle 82.9°(H), 51.9°(V) Video Resolution 1280x800@30fps, 1280x720@30fps, 640x480@30fps, 320x240@30fps, 176x144@30fps Minimum Illumination 0.1 lux @F1.8 (IR off) 0 lux @F1.8 (IR on) DC IRIS Shutter Speed 1/10~1/1000... - Page 59 Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or above Mobile Support iOS 5 or above, Android 2.3 or above. Suggested Minimum Hardware Intel Dual Core 2.53G,RAM: 1024MB, Graphic card: 128MB Intel-C 2.8G, RAM: 512MB, Graphic card: 64MB © 2014 Wirepath Surveillance...
-
Page 60: Dimensions
WPS-550-BUL-IP Installation Manual 14. Dimensions 9.07in. 8.39in. 3.24in. 3.73in. 0.6in. Ø 3.06in. -
Page 61: Warranty
This warranty shall not apply to products that have been abused, modified, disassembled, or improperly installed. Products to be repaired under this warranty must be returned to Wirepath™ Surveillance or a designated service center with prior notification and an assigned return authorization number (RA). - Page 62 © 2014 Wirepath™ Surveillance 140825-1900...
