Changes the orientation of the image based on the mounting method. Default is
Video
configured for standard mounting from a ceiling or eave. Select Flip or Mirror to
Orientation
change the orientation of the image.
Select Day and Night settings for the camera:
Day & Night
EXT Light Sensor Mode: Uses camera light sensor to switch between Color (Day)
and B&W (Night) modes. See Night to Day Lux / Day to Night Lux below.
Color Mode (Day): Forces camera to Color (Day) mode only. Useful for scenes that
will be consistently lit and when color video is always preferred.
B&W Mode (Night): Forces camera to B&W (Night) mode only, increasing low-light
performance. Useful for scenes that will consistently be poorly lit.
Time Mode: Forces camera to switch between Color and B&W modes at specific
times. See Time: below.
DI Sync: Selects Color and B&W modes based on the state of a contact output from
an external device (such as a security lighting sensor) connected to the camera's DI
input. When the connection is Open the camera switches to Color (Day) mode; when
the connection is Closed, camera switches to B&W (Night) mode.
Displayed only when Day & Night set to EXT Light Sensor Mode.
Night to Day
Lux
Sets the detected light level at which the camera will switch from B&W (Night) mode
to Color (Day) mode. Selected level must be at least 4 higher than Day to Night Lux
setting.
Displayed only when Day & Night set to EXT Light Sensor Mode.
Day to Night
Lux
Sets the detected light level at which the camera will switch from Color (Day) to B&W
(Night) mode. Selected level must be at least 4 lower than Night to Day Lux setting.
Displayed only when Day & Night set to EXT Light Sensor Mode.
Current Lux
Displays current lighting level detected by the camera's light sensor
Displayed only when Day & Night set to Time Mode.
Time
Allows setting specific Day and Night times (HH:MM) that the camera will switch
between Color (Day) and B&W (Night) modes.


Selects DNR (Digital Noise Removal) level.
DNR


Times must be entered in 24-hour format (example: 5:00PM is entered as
"17:00").
Select "Save Times" button to save new settings to the camera.
DNR can reduce some digital noise that occurs in dimly lit scenes. Default
is 1 (low).
Recommend using the lowest setting that provides adequate image quality.
