Engine Mount - THE WORLD MODELS CAP 232-46S Instruction Manual

10
Fuel Tank
11

Engine Mount

M4x25mm Socket Head Screw
4
Washer
d4xD9mm
4
Engine Mount PL5111050
!
Blind nuts are off-centered to keep
the spinner at the fuselage axis.
12
Servo Set
Set Screw
3 x 3mm
1
Linkage Connector
1
Nut
M2
1
Washer
2mm
2
Balsa 10x10x114mm
(For Fuel Tank Position Fixing)
Fuel Tank
260cc
Fuel Tank
260cc
UP
M4x25mm
Socket Head Screw
d4xD9mm
Washer
2mm
2mm
2mm
M2 Nut
Please refer to attached sheet for linkage connector installation.
P.6
Bottom View
Apply thread locker to screws.
3mm
Throttle Servo.
