ZERO FIGHTER EP ( 40 )
ZERO FIGHTER EP ( 40 )
Requires: 5-channel radio w/ 5 mini servos. Outrunner
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co., Ltd.
www.theworldmodels.com
E310PO28751302
Motor KM0374811 w/ Propeller Adaptor HW2340102
40A Brushless ESC,11x8E Propeller, 4 cells 14.8V
3200 mAh Li-Po battery & charger.
*Specifications are subject to change without notice.*
Specifications
50 in / 1270 mm
428 sq in / 27.6 sq dm
3.5 Ib / 1600 g
42 in / 1065 mm
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF)SERIES
MADE IN CHINA
( E310 )
Advertisement
Table of Contents
Related Manuals for THE WORLD MODELS ZERO FIGHTER 40
Summary of Contents for THE WORLD MODELS ZERO FIGHTER 40
- Page 1 Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. FACTORY PRE-FABRICATED The World Models ALMOST-READY-TO-FLY(ARF)SERIES Manufacturing Co., Ltd. MADE IN CHINA www.theworldmodels.com...
-
Page 2: Before You Begin
ZERO FIGHTER EP ( 40 ) ZERO FIGHTER EP ( 40 ) INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.11 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. -
Page 3: Parts List
Parts List 1. MAIN WING -- 1 pair 11. SOCKET HEAD SCREW M3x12mm -- 4 pcs WASHER d3xD7mm -- 4 pcs 2. RETRACTABLE LANDING GEAR -- 1 pair COWLING --1 pc. MAIN LANDING GEAR COVERS -- 1 pair SCREW PWA2.3x8mm -- 4 pcs PVC PLATE 0.5mm -- 2 pcs SPINNER Ø62mm PL2111062 -- 1 set SCREW PA3x12mm -- 2 pcs... -
Page 4: Retractable Landing Gear
Main Wing Apply instant type CA glue to both sides of each hinge. Aileron Servo Lead Bottom View Retractable Landing Gear Bottom View Aileron Servos Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole marks at under side of control surfaces. PB2x14mm Screw Straper... -
Page 5: Retract Servo
Main Wing Please dry fit wing joiner into left and right wing to make sure they fit with the proper dihedral angle, mark the wing joiner if necessary. Apply epoxy glue to both sides of all surfaces in contact. Use a stick to apply the glueto inner side of wing joiner sleeve, and apply the glue to wing joiner before putting them together. -
Page 6: Stabilizer & Elevator
Stabilizer & Elevator (Stabi l i zer) (Mai n Wi ng) B=B' A=A' Temporary install the main wing, adjust leveling of the stabilizer Remove coverings for all surfaces in to make it as parallel to the main wing as possible contact before applying A/B epoxy glue. -
Page 7: Rudder Pushrod
Rudder Pushrod PB2x10mm Screw Ø1m m pilot holes for Wor ld Models hor n ar e pr e-dr illed. Please look for pin-hole m ar ks at under side of contr ol sur faces. Rudder Pushrod Ø1.4x 557mm Clevis Horn Fuel Tube d2xD4x4mm PB 2 x 10mm... -
Page 8: Optional Parts
Outrunner Motor / Cowling M3x12mm Socket Head Screw Outrunner Motor 37/ 48 Deluxe Optional Parts KM0374811 PA3x12mm Screw d3xD7mm Washer TWM HW3111700 PROPELLER ADAPTOR WRENCH Propeller Adaptor HW2340102 PWA2.3x8mm Screw 11x8E Propeller PL6211108 Motor Mount PL5404000 Make sure rotating motor casing is not Motor KP0011310 in contact with... -
Page 9: Battery Cover
Battery Cover Sponge Battery Tie Battery Completed Radio Equipment Install and arrange the servos as shown in the diagram. J1(Pushrod Ø1.4x55mm) Elevator Pushrod Ø1.4x55mm Pushrod Connector M2 Nut J2(Pushrod Ø1.4x475mm) Straper Elevator Servo Fuel Tube d2xD4x4mm KM1.7x6mm Pushrod Front Charge Receptacles Elevator Servo Elevator Pushrod KP0041300... - Page 10 Main Wing PM2.5x25mm Screw d2.5xD8mm Washer PM2.5x25mm d2.5xD8mm Washer Bottom View Canopy First insert the grommet to the canopy then apply screw. PWA2.3x8mm Screw Front Antenna Lazyback Pilot Front PWA2x8mm E310PO28751302...
- Page 11 Wing Setting A=A` B=B` C=C` P.10 E310PO28751302...
-
Page 12: Control Throws
Control Throws Adjust the control throws as shown in the diagram. These throws are good for general flying. You can adjust according to your personal preference. Elevator 10mm 10mm Rudder 15mm 15mm Ailerons C.G. The ideal C.G. position is 76mm ( 3 in. ) behind the leading edge measured at where the wing meets the fuselage. -
Page 13: Landing Gear
Warning! Important Safety Precautions # First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary. # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. KM0374811 Outrunner Motor ZERO FIGHTER EP ( 40 ) ZERO FIGHTER EP ( 40 ) - Page 14 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
- Page 15 Pl8210010 Large Clevis Small Clevis Outrunner 37 / 48 Deluxe KM0374811 40A Brushless ESC Code No. Size KC2040A02 55 x 28 x12mm 1 pc -Kv (rpm / V): 770 -Operating Power: 450 W -Operating Voltage: 8.5 - 18V -Operating Current: 30A -Peak Current: 38A (max.15 sec.) -Internal Resistance: 34 m ohms -Diameter: 37.2 mm...
- Page 16 The World Models Manufacturing Co., Ltd. www.theworldmodels.com E310PO28751302...
