Main Wing
15
Screw
PM 4x30mm
4
Washer
d4xD15mm
4
16
Cowling
Screw
PWA2.6x12mm
4
d1.5 x D6.5 mm Silicon Grommet
4
Canopy
17
Screw
PWA2.3 x 8mm
Silicon Grommet
d1.5 x D6.5 mm
4
PWA2.3 x 8mm
d1.5xD6.5mm
Silicon Grommet
4mm
PM4x30mm
Please refer to attached sheet for usage of the transparent
3D template.
First insert the grommet to the cowling then apply screw.
Spinner
1mm
P.8
Wing Protection
2x30x88mm
d4xD15mm
Washer
1mm
PWA2.6 x 12mm
Pilot
First insert the grommet
to the canopy then
apply screw.
d1.5 x D6.5 mm
Silicon Grommet
