FUN WORLD 40
Requires: (Engine powered) 2-stroke 0.40 - 0.46 engine
4-channel radio w/ 5 standard or mini servos
(Electric powered) 450W motor system
4-channel radio w/ 4 standard or mini servos
40A ESC, 4 cells 14.8V 3200 mAh Li- Po
battery & charger
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this
kind of engine / electric powered precision model. Operating this model without prior preparation may
cause injuries. Remember, safety is the most important thing. Always keep this instruction
manual at hand for quick reference.
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
Specifications
*Specifications are subject to change without notice.*
50 in / 1270 mm
700 sq in / 45.2 sq dm
3.6 lbs / 1650 g
50.5 in / 1290 mm
ALMOST-READY-TO-FLY (ARF) SERIES
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
MADE IN CHINA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for THE WORLD MODELS FUN WORLD 40
Summary of Contents for THE WORLD MODELS FUN WORLD 40
- Page 1 INSTRUCTION MANUAL FUN WORLD 40 Requires: (Engine powered) 2-stroke 0.40 - 0.46 engine 4-channel radio w/ 5 standard or mini servos (Electric powered) 450W motor system 4-channel radio w/ 4 standard or mini servos 40A ESC, 4 cells 14.8V 3200 mAh Li- Po battery &...
-
Page 2: Before You Begin
FUN WORLD 40 I N D E X BEFORE YOU BEGIN P. 1 P. 2 PARTS LIST ASSEMBLY P.3-P.12 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. -
Page 3: Parts List
Parts List 1. MAIN WING -- 1 pair 10. COWLING -- 1 pc. TRANSPARENT DUMMY COWLING -- 1 pc. 2. SCREW PB2x12mm -- 4 pcs SCREW PWA2.6x12mm -- 4 pcs CLEVIS -- 2 pcs SILICON GROMMET d1.5xD6.5mm -- 4 pcs STRAPER -- 2 pcs SPINNER Ø52mm -- 1 set FUEL TUBE Ø6x5mm -- 4 pcs... -
Page 4: Aileron Servo
Main Wing Apply instant type CA glue to both sides of each hinge. Aileron Servo Lead Bottom View Aileron Servo Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole marks at under side of control surfaces. PB2x12mm Screw Aileron Servo Lead Straper... -
Page 5: Stabilizer & Elevator
Stabilizer & Elevator Apply instant type CA glue to both sides of each hinge. (Stabilizer) (Main Wing) Temporary install the main wing, adjust leveling of the stabilizer to make it as parallel to the main wing as possible. *Also refer to step 18 Wing Setting. -
Page 6: Tail Landing Gear
Tail Landing Gear PA2.6x12mm Screw set screw PA2.6x12mm PA2.6x12mm PM2x10mm Screw 1.5mm 2.1mm Collar Wheel 23mm Ø M2 Nut set screw M2 Nut PM2x10mm 0.3mm Plate Bottom View Ø1mm pilot holes for World Models tri-horn are pre-drilled. Elevator Pushrod Please look for pin-hole marks at under side of control surfaces. PB2x12mm Screw TWM PL8210010 CLEVIS WRENCH... - Page 7 This step is for engine powered. Please follow A262SGPTS step 9B if your model is electric powered. To complete your Fun world 40 (nitro powered), you need to purchase The World Models A262SGPTS. Apply thread locker to screws. Blind nuts are off-centered to keep the spinner at the fuselage axis.
- Page 8 Electric If Fun world 40 is electric powered, please follow this step. M2.5x12mm Socket Head Screw A262SEPTS To Complete your Fun world 40 (electric powered), M3x8mm you need to purchase Socket Head Screw The World Models A262SEPTS. d3xD7mm Washer d3xD7mm...
-
Page 9: Main Landing Gear
First insert the grommet to the cowling then apply screw. Cowling & Spinner Please refer to the attached sheet for usage of the transparent 3D template. PWA2.6x12mm Screw Nitro Powered Electric Powered d1.5xD6.5mm SIlicon Grommet Spinner Ø52mm Spinner Ø52mm d1.5xD6.5mm d1.5xD6.5mm PWA2.6x12mm PWA2.6x12mm... - Page 10 Main Wing Wing Tube D14.5x324mm Eye Screw PA2.5x10x23mm 1.5mm Aileron Servo Lead Rubber Band Bottom View Completed...
-
Page 11: Radio Equipment
Radio Equipment Install and arrange the servo as shown in the diagram. PWA2x8mm Screw If you choose mini servo, please add Front this step. Plywood 2x72x122mm Completed Bottom View Elevator Pushrod J1(Pushrod Ø1.8x80mm) Nitro Powered Ø1.8x80mm Pushrod Connector M2 Nut J2(Pushrod Ø1.8x560mm) Elevator Servo KM2x8mm... - Page 12 Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A=A' B=B' C=C' D=D' P.11...
-
Page 13: Control Throws
2C 0.40 - 0.46 engine or 450W motor system. FUN WORLD 40 using a more powerful engine does not mean better performance. In fact, over powered propulsion system may cause structural damage and injuries. - Page 14 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
- Page 15 Product Registration Form (US Customers) We would like to share with you any relevant information regarding your model, including product news and free upgrade parts when applicable. Please fill in the following and send to AirBorne Models, 2403 Research Drive, Livermore, CA 94550 USA. 1.
- Page 16 Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
- Page 17 Pl8210010 Large Clevis • Small Clevis • Radial Mount Adaptor Set HW2340300 1 set Outrunner 37 / 48 Deluxe KC2040A02 55x28x12mm 1 pc. KM0374810 -Voltage Range: / -Current: 40A continuous -Burst current (<10 seconds): 55A -Max speed: 13860 rpm -Weight: 33g (with wires) -Kv (rpm / V): 770 -BEC output: 3A -Operating Power: 450 W...
- Page 18 Ｐａｔｔｅｒｎ Ｄｕｃｔｅｄ Ｆａｎ Ｆｕｎｆｌｙ Ｗａｒｂｉｒｄｓ Ｓｃａｌｅ Ｅｌｅｃｔｒｉｃ Ｓｐｏｒｔｓ Ｇｌｉｄｅｒ Ｂｏａｔ Ｔｒａｉｎｅｒ Ａｃｃｅｓｓｏｒｉｅｓ Ｃｏｖｅｒｉｎｇ （Ｌｉｇｈｔｅｘ ／ Ｔｏｕｇｈｌｏｎ） The World Models Manufacturing Co., LTD. www.theworldmodels.com A262SPO21510908...
