Requires: 4-channel radio w/ 4 mini servos. Outrunner
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co., Ltd.
www.theworldmodels.com
E337XMPO28991306
Motor KM37490750 w/ Propeller Adaptor HW2340300
40A Brushless ESC,11x8E Propeller, 4 cells 14.8V
3200 mAh Li-Po battery & charger.
*Specifications are subject to change without notice.*
Designed by Jerry Small and Dan Kane
Specifications
52.2 in / 1325 mm
392 sq in / 25.3 sq dm
3.4 Ib / 1540 g
38.6 in / 980 mm
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF)SERIES
MADE IN CHINA
( E337XM )
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for THE WORLD MODELS Outregeous
Summary of Contents for THE WORLD MODELS Outregeous
- Page 1 Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. FACTORY PRE-FABRICATED The World Models ALMOST-READY-TO-FLY(ARF)SERIES Manufacturing Co., Ltd. MADE IN CHINA www.theworldmodels.com...
-
Page 2: Before You Begin
INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.11 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. -
Page 3: Parts List
Parts List 1. MAIN WING -- 1 pair 7. PUSHROD Ø1.8x410mm w/ Threads (For Elevator) -- 1 pc. SCREW PB2x10mm -- 2 pcs 2. PUSHROD Ø1.8x76mm w/ Threads (For Aileron) -- 2 pcs HORN PL4113101 -- 1 set SCREW PB2x14mm -- 4 pcs CLEVIS PL4112103 -- 1 pc. - Page 4 Main Wing Apply instant type CA glue to both sides of each hinge. Aileron Servo Lead Bottom View Aileron Servos Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole PB2x14mm Screw marks at under side of control surfaces. PA1.7x8mm Screw Straper...
- Page 5 Stabilizer & Elevator , Vertical Fin & Rudder M3x20mm Socket Head Screw d3xD7mm Washer Apply instant type CA glue to both sides of each hinge. A=A' (Stabi l i zer) (Mai n Wi ng) B=B' Washer d3xD7mm Temporary install the main wing, adjust leveling of the stabilizer to make it as M3x20mm...
-
Page 6: Tail Landing Gear
Tail Landing Gear Plastic Ring Bottom View Main Landing Gear PM4x30mm Screw Wheel Ø58mm Set Screw M4x16mm d4xD9mm Washer M4x16mm Socket Head Screw PM4x30mm KA2.3x8mm Screw M4 Nut d2xD8mm d4.5xD9mm Washer Quick Release Nylon Rivet Plastic Collar 4.1mm Plate 1mm Collar Bottom View d2xD8mm... -
Page 7: Rudder Pushrod
Rudder Pushrod PB2x10mm Screw Ø1m m pilot holes for Wor ld Models hor n ar e pr e-dr illed. Please look for pin-hole m ar ks at under side of contr ol sur faces. TWM PL8210010 CLEVIS WRENCH Rudder Pushrod Ø1.8x 450mm Clevis Horn... - Page 8 Main Wing HM5x25mm Screw d5xD12mm Washer Wing Tube Ø12x314mm HM5x25mm d5xD12mm Washer Completed E337XMPO28991306...
-
Page 9: Optional Parts
Outrunner Motor / Cowling PWA2.3x8mm Screw Optional Parts Outrunner Motor 37/ 49 - 750kv Propeller Adaptor KM37490750 HW2340300 Silicon Grommet d1.5xD6.5mm TWM HW3112400 PROPELLER ADAPTOR WRENCH 11x8E Propeller PL6211108 X- Mount Plate/Pole Make sure rotating motor casing is not in contact with M3x30 mm Aluminum Pole wirings or anything. -
Page 10: Radio Equipment
Radio Equipment Install and arrange the servos as shown in the diagram. Front Elevator Pushrod Elevator Servo Battery Receiver Ø1.8x410mm Straper Rudder Pushrod Rudder Servo Sponge Battery Mat Battery Tie Fuel Tube Ø1.8x450mm D6x5mm 2X50x150mm 200 mm Plywood 3x26x45mm Canopy Bottom View Front Front... - Page 11 Wing Setting A=A` B=B` C=C` D=D` E=E` F=F` E337XMPO28991306 P.10...
-
Page 12: Control Throws
Control Throws Adjust the control throws as shown in the diagram. These throws are good for general flying. You can adjust according to your personal preference. HIGH Elevator Rudder 10mm 10mm Ailerons HIGH C.G. The ideal C.G. position is 60.3mm ( 2 3/8 in. ) behind the leading edge measured at where the wing meets the fuselage. -
Page 13: Important Safety Precautions
Warning! Important Safety Precautions # First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary. # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. KM37490750 Outrunner Motor is specially designed to be powered by # Make sure the air field is spacious, never fly the plane too close to people and never get too close to a running... - Page 14 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
- Page 15 Pl8210010 Large Clevis Small Clevis Radial Mount Adaptor Set HW3112400 EZ Connector Puller Code No. Size Package PL8210030 1 set Outrunner Motor 37 / 49 -750kv KM37490750 40A Brushless ESC (2-4S) Code No. Size KC2040A02A 65 x 25 x12mm 1 pc -Kv (rpm / V): 750 -Operating Power: 590 W -Operating Voltage: 8.5 - 18V...
- Page 16 The World Models Manufacturing Co., Ltd. www.theworldmodels.com E337XMPO28991306...
