Parts List - THE WORLD MODELS CAP 232-46S Instruction Manual

Parts List

. --
1 MAIN WING 1 pair
. --
2 WING JOINER 6x30x203mm 1 pc
. --
3 SCREW PM2x25mm 6 pcs
--
SCREW PWA2x8mm 8 pcs
--
CLEVIS 2 pcs
--
STRAPER 2 pcs
--
FUEL TUBE Ø6x5mm 4 pcs
- ( )--
TRI HORN M3x14mm S 2 sets
. /
PUSHROD Ø1 8x105mm w Threads For Aileron
--
SERVO MOUNTING PANEL 1 pair
. & --
4 STABILIZER ELEVATOR 1 set
-- .
FUSELAGE 1 pc
. & --
5 VERTICAL FIN RUDDER 1 set
. --
6 TAIL LANDING GEAR 1 set
--
SCREW PA3x12mm 2 pcs
. / --
COLLAR 2 1mm w set screw 1 set
-- .
TAIL WHEEL Ø23mm 1 pc
. .
7 PUSHROD Ø1 8mmx720mm w Threads For Rudder
--
SCREW PM2x16mm 3 pcs
-- .
CLEVIS 1 pc
-- .
FUEL TUBE Ø6x5mm 1 pc
- ( )--
TRI HORN M3x14mm S 1 set
. . /
8 PUSHROD Ø1 8x485mm w Threads For Elevator
--
SCREW PM2x16mm 6 pcs
--
CLEVIS 2 pcs
--
FUEL TUBE Ø6x5mm 2 pcs
- ( )--
TRI HORN M3x14mm S 2 sets
. -- .
9 MAIN LANDING GEAR 1 pc
. / --
COLLAR 4 1mm w set screw 4 sets
. --
SCREW PA2 6x6mm 4 pcs
SOCKET HEAD SCREW M3x16mm 3 pcs
--
SCREW PM4x35mm 2 pcs
--
WASHER d4xD9mm 4 pcs
--
WASHER d3xD7mm 4 pcs
--
M4 NUT 2 pcs
--
MAIN WHEEL Ø58mm 2 pcs
PLATE 1mm --- 1 pair
--
WHEEL PANTS 1 pair
.
( )--
2 pcs
/ ( )--
2 pcs
( )--
2 pcs
--
. --
10 FUEL TANK 260cc 1 set
(
BALSA 10x10x114mm For Fuel Tank Position Fixing
.
11 ENGINE MOUNT PL5111050
SOCKET HEAD SCREW M4x25mm -- 4 pcs
--
WASHER d4xD9mm 4 pcs
.
12 LINKAGE CONNECTOR Ø2 1mm
. --
13 SCREW PM3x25mm 4 pcs
--
M3 NUT 8 pcs
--
WASHER d3xD7mm 8 pcs
THROTTLE PUSHROD Ø1 2x312mm
PLASTIC TUBE d2xD3xd160mm
. . (
14 BALSA 6x6x95 5mm For Fuselage Servo
.
PUSHROD Ø1 8x145mm For Elevator
--
FUEL TUBE Ø6x5mm 2 pcs
--
STRAPER 2 pcs
PUSHROD CONNECTOR
. .
PLYWOOD 3x100 5x110 1mm For Fuselage Servo
(
SPONGE For Radio Equipment
. --
15 SCREW PM4x30mm 2 pcs
--
WASHER d4xD15mm 2 pcs
(
PLYWOOD 2x30x88mm Wing Protection
. -- .
16 COWLING 1pc
TRANSPARENT 3D TEMPLATE
. --
SCREW PWA2 6x12mm
.
SILICON GROMMET d1 5xD6 5mm
-- .
SPINNER Ø62mm 1 pc
. -- .
17 CANOPY 1 pc
. --
SCREW PWA2 3x8mm
.
SILICON GROMMET d1 5xD6 5mm
( )--
PILOT PC001085C 1 pc
. -- .
18 DECALS 1 pc
COVERING:--
TOUGHLON STL 100 WHITE
TOUGHLON STL 240 GREEN
TOUGHLON STL 312 BRIGHT RED
TOUGHLON STL 204 CREAM
TOUGHLON STL 412 CHECKER RED WHT
P.2
)--
1 pc
--
1 set
. --
1 set
. -- .
1 pc
-- .
1 pc
)-- .
1 pc
( )-- .
1 pc
--
1 set
( )--
1 pc
)-- .
1 pc
)-- .
1 pc
-- .
1 pc
4 pcs
. --
4 pcs
4 pcs
. --
4 pcs
.
(
/
.
.
)
