Chapter 24
24.8 PnP/PCI Configurations
Feature
Init Display First
Reset Configuration Data
Resources Controlled by
First/Second PCI IRQ
24.9 PC Health Status
Feature
System Temp. (Local)
CPU Die Temp. (Remote)
Shutdown Temperature
Board Voltage +Vcore
Board Voltage +3.3V
System Voltage +5.0V
System Voltage +12.0V
Kontron User's Guide MOPSlcdLX
Option
Onboard
Defines the primary Video controller. If no ISA Video
adapter exists, no falling back to Onboard control-
ISA Slot
ler is realized
PCI Slot
Disabled
Enabled erases all configuration data in Extended
System Configuration Data (ESCD), which stores the
Enabled
configuration settings for plug-in devices
Auto(ESCD)
Selects Auto the system BIOS configure all PnP data
Manual allows user configuration of PCI IRQs
Manual
IRQ3
The system BIOS must have two PCI IRQs. PCI inter-
rupts own the highest priority and disabling legacy
IRQ4
(ISA) IRQs, also internal Serial and Parallel ports
IRQ5
IRQ7
IRQ10 (First)
IRQ11 (Second)
IRQ12
IRQ15
Option
N/A
Temperature of onboard LM84 sensor (local tempe-
rature)
N/A
Temperature of CPU Die (LM84 remote temperature)
Disabled
Defines the shutdown temperature
0
0
0
60
C, 65
C, 70
C,
0
0
0
75
C, 80
C, 85
C,
0
0
0
90
C, 95
C, 100
C,
0
0
100
C, 105
C,
0
0
110
C, 115
C,
0
0
120
C, 125
C
N/A
Vcore voltage (generated onboard)
N/A
3.3V voltage (generated onboard)
N/A
5.0V voltage (external power supply)
N/A
12.0V voltage (external power supply)
45
