Chapter
4
To create or configure an Ethernet LAN DMZ connection:
1. Select the Service management > Network service management > Network
connections menu. This opens the connection list.
2. If you are creating a new connection:
a. Click Add.
b. Select the Ethernet LAN DMZ option
c. Click OK.
Otherwise, if you are modifying an existing Ethernet LAN DMZ connection:
a. Select the Ethernet LAN DMZ connection in the list.
b. Click the modification button
3. In the displayed form, enter the connection name. You can give any name that clearly
identifies the connection.
4. Enter the network connection settings:
• Network connection IP address.
• Network mask or equivalent prefix.
• If there is an external gateway, enter the gateway address.
5. If several network interfaces are available, select the Ethernet interface (ethx). This field is
read-only in all other cases.
6. Activate the interface by selecting Yes.
7. Validate the settings by clicking OK.
4.3.6

Ethernet LAN Alias Connection

Use an "Ethernet LAN Alias" connection to create a virtual interface from an existing one. In
this way, you can assign different IP addresses to one physical network interface.
To create or configure an Ethernet LAN Alias connection:
1. Select the Service management > Network service management > Network
connections menu. This opens the connection list.
2. If you are creating a new connection:
a. Click Add.
b. Select the Ethernet LAN Alias option
c. Click OK.
Otherwise, if you are modifying an existing Ethernet LAN Alias connection:
a. Select the Ethernet LAN Alias connection in the list.
b. Click the modification button
3. In the displayed form, enter the connection name. You can give any name that clearly
identifies the connection.
4. Enter the network connection settings:
• Network connection IP address.
• Network mask or equivalent prefix.
5. If several network interfaces are available, select the physical Ethernet interface (ethx).
This field is read-only otherwise.
4-8
.
.
