Alcatel-Lucent Extended Communication Server Installation & Configuration Manual page 126

Chapter
11
• In Troubleshooting tab, select the user who receives emails in error
• This operation must be repeated for every user receiving faxes
11.4.2.3 Receiving Faxes via a Forward SMTP
If the pop connector is not implemented in the Windows® server, it is possible to forward faxes
from the Extended Communication Server to the Exchange® server via a SMTP connector
and an email forwarding rule. This forwarding rule should be setup in each Extended
Communication Server users' accounts receiving faxes. The target email address should be
the user's active directory email address.
In this example, the user has 2 email addresses:
- user@eman704.dyndns.org (Primary email address)
- user@server1.local (Secondary email address created by default in the active
directory domain)
- In the Extended Communication Server administration interface, Menu Services
management > Email > SMTP > Domain names, create the SMTP connector as shown
in the figure below :
Figure 11.46: Extended Communication Server SMTP Connector Creation
11-36
Figure 11.45: POP3 Scheduling
