Chapter
13
Note:
By default, VoIP telephony is activated for all users.
3. Click OK.
13.3
Configuration For Interoperability With OmniPCX Office
After reading this section, you will be able to carry out SIP telephony over the internet between
a user connected on Virtual Desktop and a user of the OmniPCX Office.
13.3.1
Prerequisites
-
Basic Configuration for SIP Telephony over the internet must be performed.
-
Alcatel-Lucent OmniPCX Office Communication Server must be R7.0 or higher and SIP
trunking must be configured.
13.3.2
Configuring Interoperability with OmniPCX Office
1. Select the Service management > OmniPCX Office > Detection and Configuration
menu.
2. Select the IP detection tab.
3. Click the Detection of the OmniPCX Office IP address button.
After some seconds, the OmniPCX Office IP address is displayed.
4. Click OK and activate the service.
5. Select the Service management > Telephony over Internet (VoIP - SIP) >
Configuration menu.
13-4
