Installation

Front Panel connections

Data
Socket
IR
USB
LED

Rear Panel connections

32 Input model
16 Input model
12 Input model
10
Can be used to connect an external IR receiver to replace the
internal unit
Infra-Red receiver for use with Remote Control
USB2.0 connector
Four LEDs show the unit status
Green - Unit working normally
Flash Orange - IR being received
Solid Red - Unit working but outside normal parameters
Flashing Red - System not operational (i.e. in boot up)
No LED - Power Failure
