Features

• 8, 12, 16 or 32 camera input options (4 camera input model available after future
development)
• Field serviceable hard drives
• Telemetry support (Coax & Serial)
• All DVR functions fully supported by Keyboard/IR Remote Control
• Scalable recording settings of either 50pps 75pps or 100pps
• MultiMode Recording - Dynamically-switchable resolution, record-rate & compression
(MPEG4/JPEG) per camera
• Single, Picture in Picture and Multiway displays
• Live and playback viewing locally and over Ethernet
• Built in activity detection
• JPEG or MPEG-4 recording and transmission
• Built in CD-R writer and USB ports for download of video archive to external flash
memory
• Web pages provide easy remote configuration
• Alarm Inputs & Outputs
• Easy to use on-screen, colour coded soft keys
• BS8418 compliant
• Text support and text search features ideal for retail installations
• Optional external keyboard available
• Configuration via USB mouse and USB QWERTY keyboard.

Design of the manual

The manual has three parts:
1. Installation
2. Configuration
3. Operation
The order and layout of these pages has been designed to help the setup process. It is
recommended that the menus are edited sequentially (as they appear on the page), to enable
accurate, easy and efficient setup.

Shows details of how to install the unit and connect external devices.
Shows details of the units menus.
Shows quick reference details on how to control the unit.
