Dedicated Micros SD Range Installation And Operation Manual page 16

Step  Connecting Audio
The SD supports either one or two channels of bi-directional audio*, accessible through NetVu
ObserVer. Connect the audio equipment to the phono sockets AUDIO IN and AUDIO OUT. The
audio channel defaults to recording camera 1.
* 32 input model supports two channels of bi-directional audio, 8, 12 and 16 input models
support one.
The following modes of operation are supported:
Note:
Step  Connecting to the Network
The SD supports a 10/100Mbps auto-detecting network port. Use a CAT5 cable to connect the unit
to the network.
By default the unit is configured for DHCP where the unit is automatically allocated an IP address
from the network DHCP server.
1
• Challenge – intruders from an RVRC.
• Listen – to local audio from a site at the RVRC.
• Record - local audio from a site with the video.
• Replay - all audio through a local Audio output (not supported when
Audio out is used as a challenge/PA source).
The Audio ouptut can be configured as a challenge output or as a replay output.
