Installing the Unit

Before you start

Check the contents of the box

The following items are included in the box:
Remove all items from the packaging and check the items listed below are present.
• NV4 NVR
• IR Remote Control
• Power Leads
• IR Extender Lead
• NV4 Software/Documentation CD
• Mouse
• Rack Mounting brackets
• RS485 Telemetry Adaptor
• Quick Start Guide
If any of these items are missing please contact Dedicated Micros Technical Support team.
Note: Before installing the NV4 DVR, carefully read all Safety Instructions and the following information
on where the unit should be located.

Choosing a location for installation

• The NV4 is designed to be desk, shelf or rack mounted. Rack mounting brackets are
available as an optional accessory.
• Ensure the NV4 unit is properly ventilated to protect from overheating.
• Ensure there is a 3cm gap on both sides of the unit.
• Ensure the IR receiver on the front of the unit faces the operator position, and is not more
than 10 feet (3 metres) from the operator. An IR Remote Control Extender is also available.
• Ensure the unit is not located anywhere it could be subject to mechanical shocks.
• The unit should be located in an area with low humidity and a minimum of dust. Avoid places
like damp basements or loft spaces.
• If the unit is to be installed in a closed assembly, the maximum operating temperature must
not exceed 40°C (104°F).
• Ensure there is reliable earthing of the mains outlet when fitted to supply connections (other
than direct connection to the branch circuit).
• Any branch circuit supplying the unit must be rated at 15Amps.
• It is recommended that an uninteruptable power source be connected to the unit in case of
power failure (to ensure continuous operation of the unit).
