Selective Color Correction; The Selective Color Correction Dialog Box - Names Of Parts; Reset - Minolta DiMAGE Scan Multi PROAF-5000 Instruction Manual

SELECTIVE COLOR CORRECTION

Separate the color region into 7 groups, Red, Green, Blue, Cyan, Magenta, Yellow and Black.
You can adjust the color range of each processed color Cyan, Magenta, Yellow, and Black
against the separate color groups. You can use this if you wish to add or remove a certain
color only and not the whole picture, or if you wish to remove an unwanted color from a
particular color. For instance, if you want the sky look vividly blue instead of purplish, decrease
the component amount of Magenta from Blue to obtain a very blue sky.
Click on in the Image Correction tab.
THE SELECTIVE COLOR CORRECTION
DIALOG BOX — NAMES OF PARTS
Color list box
CMYK slider
1. Click on the arrow next to the Color
list box to display the color range to
be corrected.
2. Drag the Cyan (C), Magenta (M),
Yellow (Y) or Black (K) slider or input
the desired value in the text box.
• The value from -100 to 100 can be input.
• The change will not be reflected in the
prescan image.

RESET

If you click [Reset] button, the settings in the current correction
window are reset.
CMYK text box
Reset button
DiMAGE Scan Multi PRO
77
