Image resolution is the number of pixels per inch (ppi or dpi) that represent your scanned
image. The size of an image file is determined by its size (dimensions) and resolution.
The rule to follow when scanning is "bigger is better". To obtain the best results, set the output
resolution to the highest value your final output device (printer, monitor, etc.) can handle. The
driver software automatically determines the input resolution necessary to obtain the desired
output size and resolution.
1. Click on
in the Scan settings part of the window.
2. Select the appropriate
category from the drop-down list.
3. Click on the job file name to select it, then
click on
.
• The settings are applied to the active Prescan
tab.
The Job Selection dialog box will appear.
Continued on the following page.
DiMAGE Scan Multi PRO
SCAN SETTINGS
93
