• Memory content setting
Command : 1A 00
q, w Memory channel numbers
0001–0099: Memory channel 1 to 99
0100: Programmed scan edge P1
0101: Programmed scan edge P2
To clear the memory channel contents, add the
code "FF" after the memory channel number.
(instead of the data e to @7 )
This completes the memory clearing.
e Select memory setting
00 : OFF
01 : ★1
02 : ★2
03 : ★3
r~i Operating frequency setting
See "• Operating frequency."
o, !0 Operating mode setting
See "• Operating mode."
• Main or sub band's frequency settings
Command : 25
X X X X X X X X X X 0 0
00: MAIN
01: SUB
• Main or sub band's operating mode and filter
settings
Command : 26
Both data and filter settings can be skipped. In that
case, "DATA OFF" and the default filter setting of the
operating mode is automatically selected.
00: MAIN
01: SUB
Operating mode setting
(see p. 18-10)
q, w e r−i
X X X X X X X X ... X X X X X X X X X X X X X X X X X X
Operating frequency data
(See p. 18-10)
Data mode setting
(see p. 18-11)
X X X X X X X X
Filter setting
(see p. 18-10)
!2 − !4
o, !0 !1
!1 Data mode and tone type settings
!1
X
!2 ~ !4 Repeater tone frequency setting
!5 ~ !7 Tone squelch frequency setting
See "• Repeater tone/tone squelch settings."
!8 ~ @7 Memory name settings
Up to 10 characters.
See "• Codes for the memory name, opening message,
NTP server address, CLOCK2 name, network name,
and network radio name contents."
18-13
CONTROL COMMAND
!5 − !7 !8 − @7
X X X X ... X X
X
0: OFF, 1: TONE, 2: TSQL
0: OFF, 1: DATA 1, 2: DATA 2, 3: DATA 3
