15
SET MODE
■ Others set mode (continued)
CW Normal Side
Selects the carrier point in the CW normal mode.
• LSB: The LSB side.
• USB: The USB side.
APF Type
Selects the audio filter type for APF.
• SOFT: Soft sound.
The filter bandwidth is automatically changed
according to the CW pitch, to make it easier to
distinguish between noise and a signal.
• SHARP: Sharp sound.
The filter bandwidth is fixed regardless of
the CW pitch, to make it easier to reject
interfering signals.
MIC AF Out
Selects the band(s) audio to output from [MIC].
• MAIN+SUB: Outputs both MAIN and SUB bands
audio.
• SUB: Outputs only SUB band audio.
MIC Input DC Bias
Outputs the 8 V bias voltage (approximately) from the
microphone connector (pin 1 of [MIC]).
• OFF: When using a microphone that doesn't need bias
voltage (example: dynamic microphones).
• ON: W h e n u s i n g a n I c o m ' s m i c r o p h o n e o r
microphone that needs a bias voltage.
External Keypad (VOICE) OFF
Enables voice memory transmission using an external
keypad.
• OFF: Turn OFF the function.
• ON: Pushing one of the external keypad switches,
transmits the programmed voice memory (T1–
T8). (SSB/AM/FM mode)
H o l d i n g d ow n t h e sw i t c h fo r 1 s e c o n d t o
repeatedly transmit.
(Default: LSB)
(Default: SOFT)
(Default: MAIN+SUB)
(Default: ON)
(Default: OFF)
15-16
External Keypad (KEYER)
Enables keyer memory transmission using an external
keypad.
• OFF: Turn OFF the function.
• ON: Pushing one of the external keypad switches,
transmits the programmed keyer memory (M1–
M8). (CW mode)
Holding down the switch for 1 second to
repeatedly transmit.
External Keypad (RTTY)
Enables the RTTY memory transmission using an external
keypad.
• OFF: Turn OFF the function.
• ON: Pushing one of the external keypad switches,
transmits the programmed RTTY memory (RT1–
RT8). (When the RTTY decode screen is opened
in the RTTY mode)
When the external keypad is connected to [MIC], only
RTTY memory channels RT1–RT4 can be transmitted
using the external keypad.
External Keypad (PSK)
Enables the PSK memory transmission using an external
keypad.
• OFF: Turn OFF the function.
• ON: Pushing one of the external keypad switches,
transmits the programmed PSK memory (PT1–
PT8). (When the PSK decode screen is opened in
the PSK mode)
When the external keypad is connected to [MIC], only
PSK memory channels PT1–PT4 can be transmitted
using the external keypad.
Keyboard [F1]–[F8] (VOICE)
Enables the voice memory transmission using a keyboard
connected to [USB A].
• OFF: Turn OFF the function.
• ON: Pushing one of [F1] to [F8] on the keyboard,
transmits the programmed voice memory (T1–
T8).
Holding down [SHIFT] and pushing one of [F1]
to [F8] on the keyboard repeatedly transmits
memory.
(Default: OFF)
(Default: OFF)
(Default: OFF)
(Default: OFF)
