18
CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
1A 05 0079 00 to 08
0080 00 to 02
0081 00 to 02
0082 00 or 01
0083 00 or 01
0084 00 or 01
0085 00 or 01
0086 00 or 01
0087 00 to 03
0088 00 to 03
0089 00 or 01
0090 00 or 01
0091 00 or 01
0092 00 or 01
0093 00 or 01
0094 see p. 18-11
0095 20000101 to
20991231
0096 0000 to
2359
0097 00 or 01
0098 see p. 18-11
0099 see p. 18-10
0100 00 or 01
0101 see p. 18-11
0102 see p. 18-11
0103 00 or 01
0104 00 or 01
0105 00
01
02
03
0106 0050 to
0200
0107 0050 to
0200
0108 00 or 01
0109 00 to 05
Description
Send/read frequency readout font
( 00=Basic (1), 01=Basic (2), 02=Basic (3),
03=Italic (1), 04=Italic (2), 05=Italic (3),
06=Round (1), 07=Round (2),
08=Round (3))
Send/Read response speed for Standard
and Edgewise meter needle
(00=Slow, 01=Mid, 02=Fast)
Send/read meter type
(00=Standard, 01=Edgewise, 02=Bar)
Send/read meter type during expanded
screen (00=Edgewise, 01=Bar)
Send/read peak hold set for Bar meter
(00=OFF, 01=ON)
Send/read memory name indication setting
(00=OFF, 01=ON)
Send/read audio peak filter width popup
indication setting (00=OFF, 01=ON)
Send/read manual notch width pop-up
indication setting (00=OFF, 01=ON)
Send/read screen saver function
( 00=OFF, 01=15 minutes, 02=30 minutes,
03=60 minutes)
Send/read screen saver type
( 00=Bounce, 01=Rotation, 02=Twist,
03=Sleep)
Send/read output signal setting for external
display (00=OFF, 01=ON)
Send/read flame rate shift setting for external
display (00=OFF, 01=ON)
Send/read image resolution for external
display (00=800x480, 01=800x600)
Send/read synchronous pulse level setting
(00=L, 01=H)
Send/read opening message indication
(00=OFF, 01=ON)
Send/read opening message contents
(up to 10-character)
Send/read date
( 20000101=1st Jan. 2000 to
20991231=31st Dec. 2099)
Send/read time (0000=00:00 to 2359=23:59)
Send/read NTP (Network Time Protocol)
function setting (00=OFF, 01=ON)
Send/read NTP server address setting
Send/read UTC offset time
Send/read CLOCK2 function
(00=OFF, 01=ON)
Send/read UTC offset time for CLOCK2
Send/read CLOCK2 name
(up to 3-character)
Send/read calibration marker
(00=OFF, 01=ON)
Send/read confirmation beep
(00=OFF, 01=ON)
Send/read the band edge beep OFF
Send/read the band edge beep ON (Beep
sounds with a default amateur band)
Send/read the band edge beep with user
setting ON
Send/read the band edge beep with user
setting/TX limit ON
Send/read main band's beep audio
frequency (0050=500 Hz to 0200=2000 Hz)
Send/read sub band's beep audio frequency
(0050=500 Hz to 0200=2000 Hz)
Send/read TX output power limit function
(00=OFF, 01=ON)
Send/read the TX Delay setting (HF)
( 00=OFF, 01=10 ms, 02=15 ms, 03=20 ms,
04=25 ms, 05=30 ms)
Cmd. Sub Cmd. Data
1A* 05 0110 00 to 05
0111 00 to 05
0112 00 or 01
0113 00 or 01
0114 see p. 18-11
0115 see p. 18-11
0116 00 or 01
0117 00 or 01
0118 00 or 01
0119 00 or 01
0120 see p. 18-11
0121 00 to 02
0122 00 to 02
0123 00 or 01
0124 00 to 02
0125 00 or 01
0126 00 or 01
0127 00 or 01
0128 00 or 01
0129 00 or 01
0130 00 or 01
0131 00 to 02
0132 00 to 02
0133 00 or 01
0134 00 or 01
0135 00 to 02
0136 00 to 02
0137 00 or 01
0138 00 or 01
0139 00 or 01
0140 00 or 01
0141 00 or 01
0142 00 or 01
0143 00 or 01
0144 00 or 01
0145 00 or 01
0146 00 or 01
0147 00 or 01
18-6
Description
Send/read the TX Delay setting (50 MHz)
( 00=OFF, 01=10 ms, 02=15 ms, 03=20 ms,
04=25 ms, 05=30 ms)
Send/read TOT setting for remote or the
[TRANSMIT] key operation
( 00=OFF, 01=3 minutes, 02=5 minutes,
03=10 minutes, 04=20 minutes,
05=30 minutes)
Send/read quick dualwatch function
(00=OFF, 01=ON)
Send/read quick split set (00=OFF, 01=ON)
Send/read FM split offset –9.999 to
+9.999 MHz for HF
Send/read FM split offset –9.999 to
+9.999 MHz for 50 MHz
Send/read split lock set (00=OFF, 01=ON)
Send/read tuner auto start set
(00=OFF, 01=ON)
Send/read PTT tune set (00=OFF, 01=ON)
Send/read transverter set (00=OFF, 01=ON)
Send/read transverter offset
Send/read RTTY mark frequency
(00=1275 Hz, 01=1615 Hz, 02=2125 Hz)
Send/read RTTY shift width
(00=170 Hz, 01=200 Hz, 02=425 Hz)
Send/read RTTY keying polarity
(00=Normal, 01=Reverse)
Send/read PSK tone frequency
(00=1000 Hz, 01=1500 Hz, 02=2000 Hz)
Send/read speech language
(00=English, 01=Japanese)
Send/read speech speed (00=Low, 01=High)
Send/read S-level speech (00=OFF, 01=ON)
Send/read speech with a mode switch
operation (00=OFF, 01=ON)
Send/read memo pad numbers
(00=5 ch, 01=10 ch)
Send/read main dial function
(00=MAIN, 01=MAIN+SUB)
Send/read main dial auto TS
(00=OFF, 01=Low, 02=High)
Send/read sub dial auto TS
(00=OFF, 01=Low, 02=High)
Send/read mic. up/down speed
(00=Low, 01=High)
Send/read quick RIT/ TX clear function
:
(00=OFF, 01=ON)
Send/read SSB notch operation
(00=Auto, 01=Manual, 02=Auto/Manual)
Send/read AM notch operation
(00=Auto, 01=Manual, 02=Auto/Manual)
Send/read DIGI-SEL control function
(00=DIGI-SEL, 01=APF)
Send/read band indication for Filter screen
(00=Fix, 01=Auto)
Send/read SSB/CW synchronous tuning
function (00=OFF, 01=ON)
Send/read CW normal side set
(00=LSB, 01=USB)
Set/read APF type (00=SHARP, 01=SOFT)
Send/read band setting for audio output from
mic. connector (00=MAIN+SUB, 01=SUB)
Send/read bias voltage output for mic. audio
input ([MIC]; pin 1) (00=OFF, 01=ON)
Send/read external keypad set for RTTY
memory (00=OFF, 01=ON)
Send/read external keypad set for PSK
memory (00=OFF, 01=ON)
Send/read the voice memory transmission
set for [F1] to [F8] on the keyboard
(00=OFF, 01=ON)
Send/read the memory keyer transmission
set for [F1] to [F8] on the keyboard
(00=OFF, 01=ON)
