Operating Controls - Automatic Technology SECURALIFT Installation Instructions And Owner's Manual

1. LIGHT CODE button (White)
is used for storing or erasing the
transmitter button (code) you wish to
use to turn the courtesy light on the
Opener on and off.
2. DOOR CODE button (Blue) is
used for storing or erasing the
transmitter button (code) you wish
to use to command the door to open ,
stop or close.
3. CLOSE DRIVE button (Red) is
used during installation to help set the
close limit stop position. Pressing and
holding this button will move the
door in the close direction. Move-
ment stops when the button is re-
leased.
N O T E : T h e c l o s e
obstruction detection is inoperable
whenever the Close Drive button is
used to move door.
4. CLOSE LIMIT Led (Red) .the
led is very helpful during installation,
it illuminates and flashes when the
door is closing and remains steady on
when the close limit is activated
5. AUTO CLOSE button (White) is
used to adjust the auto close time.
While holding in
Close
button and then pressing (each press
will increase the time by 5 seconds)
the Open button the time is
increased, pressing the Close button
will decrease the time.
6. RESET button (white) is used to
initialise and set
opener
operating parameters, including cycle
times and obstruction force settings.
Check the installation manual for
other uses.
7. O / S / C button (Yellow) is used
during installation to test the Open,
Stop and Close cycles for the Opener.
The Opener has to be initialised by the
Reset button before the O/S/C button
O P E R AT I N G C O N T R O L S s e e F i g . 1 5
8. CLOSE
SCREW (Red) is used to fine adjust
the close limit stop position. Check
installation section on how to adjust.
9. OPEN
SCREW (Green) is used to fine
adjust the open limit stop
Check installation section on how
to adjust.
11. OPEN Drive button (Green)
is used during installation to help set
the open limit stop position.
Pressing
will move the door in the open di-
rection.
the button is released.
NOTE: The open obstruction
s a f e t y
detection is disabled whenever the
Open Drive button is used to
move door.
12. OPEN LIMIT Led (Green)
the
installation, it illuminates and
flashes when the door is opening
and
the open limit is activated
13 The cam operation is only on
ATA's EasyRoller roll-up door
the Auto
opener
14.
(white) Button is used to change
the force
door
encounters an obstruction. Pressing
the Force Margin Set button and
Open or Close button will increase
the door /
or decrease the force. Normally the
force pressure is set automatically.
The Force Margin Set is only ever
used if other environmental fac-
tors
(wind, etc.) effect the operations of
the Door/Opener.
LIMIT ADJUST
LIMIT ADJUST
position.
and holding this button
Movement stops when
led is very helpful during
remains steady on when
FORCE MARGIN
pressure when
5
15. P.E. Input is for connection of
Photo Electric Beams (optional
extra) for extra safety obstruction
protection, or compulsory when
used with Auto Close Mode.
NOTE: P.E. SHUNT must not be
removed otherwise the Opener will
not function correctly. Remove only
when a P.E. is to be connected
16 This connection is only on
ATA's EasyRoller roll-up door
opener.
17. SECURALIGHT Input is used
for connecting a Securalight
(optional extra)
Securalight is a monitor unit which
is mounted inside your home and is
connected to the Opener by wire
cable. The monitor indicates the
status of the door, for example if the
door is moving or is opened or
closed, etc. The door can also be
controlled from the monitor unit.
18. O / S / C Input is for
connecting the wired Wall Switch
(optional extra).
19. ENGAGE / DISENGAGE
HANDLE
towards door and released will select
manual mode. Used, for example
SET
when there is a power failure. Pull-
ing the handle away from door and
the
releasing again will select automatic
mode
Monitor. A
when pulled down
