Digital Projection
M-Vision Cine 320 Series

Indicators

Power indicator (blue light)
The blue Power indicator will light when the projector is in STANDBY mode, and will flash when the projector is cooling down or warming up, as
shown in the chart below. It will be off when the projector is in normal running mode.
Condition
Power indicator behaviour (blue light)
Standby
On
Cooling / Warming up
Flashing
Power on (Normal)
Off
Error codes (red light)
If the projector detects an error, the red Issue indicator will flash as shown in the chart below.
For example, if the lamp door is left open, the red indicator will flash twice followed by a pause, then the sequence will repeat until the error
condition is corrected.
Condition
Issue indicator behaviour (red light)
Lamp fail
Flashes once, then pauses, then repeats.
Fan fail
Flashes twice, then pauses, then repeats.
Over temperature
Flashes three times, then pauses, then repeats.
System error
On.
Rev D July 2014
PROJECTOR OVERVIEW
delay
delay
delay
Installation and Quick-Start Guide
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
6
