M-Vision Cine 320 Series
S-Video
4 pin mini-DIN
1
Y Ground
2
C Ground
3
Luminance (Y)
4
Chrominance (C)
Composite Video
RCA Phono
Rev D July 2014
WIRING DETAILS
pin view of female connector
Connection Guide
Notes
For full details of all input settings,
see the Main menu section in the
Operating Guide.
