Boot Up Numlock Status; Boot Up System Speed; Gate A20 Option; Typematic Rate Setting - AXIOMTEK SBC8440 User Manual

SBC8440 3.5
Form Factor SBC User's Manual


!"

Boot Up NumLock Status

This allows you to activate the NumLock function after you power up
the system. By default, the system boots up with NumLock ON.
On
Off
!"

Boot Up System Speed

It selects the default system speed - the speed that the system will run
at immediately after power up.
High
Low

Gate A20 Option

!"
This you to select how Gate A20 is worked. Gate A20 is a device used
to address memory above 1 MB. The default setting is Fast.
The A20 signal is controlled by keyboard controller or
Normal
chipset hardware.
Default : Fast. The A20 signal is controlled by Port 92 or
Fast
chipset specific method.
!"

Typematic Rate Setting

When disabled, continually holding down a key on your keyboard will
generate only one instance. When enabled, you can set the two
typematic controls listed next. By default, this field is set to Disabled.
Enable typematic rate and typematic delay programming
Enabled
Disable typematic rate and typematic delay programming.
The system BIOS will use default value of this 2 items and
Disabled
the default is controlled by keyboard.
)!

Keypad is number keys
Keypad is arrow keys
Set the speed to high
Set the speed to low
Award BIOS Utility
