SBC8440 3.5
Form Factor SBC User's Manual


Item

Blank Screen

D. Video Off
Method
DPMS
Supported
NOTE: Green monitors detect the V/H SYNC signals to turn OFF its
electron gun.
E. Modem
3
Use IRQ
Disable
F. HDD
1, 2, 3, 4, 5, 6, 7,
Power
8, 9, 10, 11, 12,
Down
13, 14, 15 Mins.
(*)
When Suspend
Remark 2
− 2nd & 3rd options above can be selected at the same
NOTE:
time.
− When HDD is in power saving mode, any access to the
HDD will wake up the HDD.
Disable
10, 20, 30, 40
G. Doze
Secs., 1, 3, 5, 10,
Mode
15, 20, 30, 40
Mins., 1, 2, 3
Hrs.
NOTE: Normally, DOZE mode puts the system into low speed or 8MHz,
screen may be OFF depending on (E).
!1

Options
The system BIOS will only blank
OFF the screen when disabling
video
This function is enabled only for
VGA cards supporting DPMS
The BIOS sets the "Modem Use
IRQ" number at IRQ3.
You can manually choose the IRQ
number.
HDD ' s motor will not turn OFF.
Defines the continuous HDD idle
time before the HDD enters power
saving mode (motor OFF)
BIOS will turn the HDD's motor OFF
when system is in SUSPEND mode.
System will never enter DOZE mode.
Defines the continuous idle time
before the system enters DOZE
mode
If any item defined in (J) is enabled
& active, DOZE timer will be
reloaded.
Continued . . . . .
Descriptions
Award BIOS Utility
