AXIOMTEK SBC8440 User Manual page 32

SBC8440 3.5
Form Factor SBC User's Manual


PIN No. PIN Name
SA6
49
SA5
51
SA4
53
SA3
55
SA2
57
SA1
59
SA0
61
0V
63
J2: PC/104 Bus Pin Assignments
PIN No. PIN Name
0V
1
MEMCS16 *
3
IOCS16 *
5
IRQ10
7
IRQ11
9
IRQ12
11
IRQ15
13
IRQ14
15
DACK0 *
17
DRQ0
19
DACK5 *
21
DRQ5
23
DACK6 *
25
DRQ6
27
DACK7 *
29
DRQ7
31
+5V
33
MASTER *
35
0V
37
0V
39
1!

PIN No. PIN Name
IRQ3
50
DACK2 *
52
TC
54
SALE
56
+5V
58
OSC
60
0V
62
0V
64
PIN No. PIN Name
0V
2
SBHE *
4
LA23
6
LA22
8
LA21
10
LA20
12
LA19
14
LA18
16
LA17
18
MEMR *
20
MEMW *
22
SD8
24
SD9
26
SD10
28
SD11
30
SD12
32
SD13
34
SD14
36
SD15
38
(KEY)
40
Hardware Description
