Common Features - Icom IC-FR3000 Series Sales Handbook

Internal space for duplexer and isolator Internal space for duplexer and isolator
Internal space for duplexer and isolator Internal space for duplexer and isolator
The repeater has an internal space to install a
duplexer and isolator*. The controls of the duplexer
are accessible from the front of the repeater without
disassembly. Faster and easier maintenance and
adjustment is possible.
*Ask your dealer for details about available duplexers and
isolators.
16- - - - digit alphanumeric display 16 digit alphanumeric display
16 16 digit alphanumeric display digit alphanumeric display
The 16-digit alphanumeric LCD displays channel
number, channel name, decoded ID (with 2-Tone and
DTMF), etc. Great for use as a base station.
Telephone interconnect capability Telephone interconnect capability Telephone interconnect capability Telephone interconnect capability
The repeater has a 4-pin modular connector allowing
telephone interconnection.
DTMF remote control capability DTMF remote control capability DTMF remote control capability DTMF remote control capability
You can control the repeater from a remote location
over the air or over a phone line with DTMF.
Programmable key assign function Programmable key assign function Programmable key assign function Programmable key assign function
The following functions can be assigned to the [PROG]
button.
• Priority A • Priority A (Rewrite) • Priority A • Priority A (Rewrite)
• Display select • Lock
• High/Low • Wide/Narrow
• Call • Call A, B (PMR mode only)
• Emergency Single • Emergency Repeat
• Scrambler • Special Function 1, 2
• Null
Wall or rack mount available Wall or rack mount available
Wall or rack mount available Wall or rack mount available
With an optional microphone, the repeater can be
placed on a desktop as a base station. The optional
MB-77 wall mount bracket allows you to set the
repeater on a wall. A 19" 3U height rack mount
bracket, MB-78, is also available.
19-inch rack mount, MB-78

Common Features

Installation on a wall with the MB-77
ADDITIONAL FEATURES ADDITIONAL FEATURES
ADDITIONAL FEATURES ADDITIONAL FEATURES
• Self check function checks for internal errors and
alerts with a beep sound or with a phone call
• Compatible with VEGA tone remote control system
• CW ID transmitter (DTMF or 5-Tone also selectable)
• Password and kill/stun function for security
All trademarks are the properties of their respective holders.
Applicable U.S. Military Specifications Applicable U.S. Military Specifications
Applicable U.S. Military Specifications Applicable U.S. Military Specifications
The MIL MIL- - - - STD STD- - - - 810 810 series of standards are issued by the
MIL MIL STD STD 810 810
United States Army's Developmental Test Command,
to specify various environmental tests to prove that
equipment qualified to the standard will survive in the
field.
Icom Icom makes rugged products
Icom Icom
that have been tested to and
passed the following MIL-STD
requirements and strict
environmental standards.
MIL 810C
Standard
Method Proc. Method
High Temp. 501.1 I
Low Temp. 502.1 I
Vibration 514.2 VIII, X
Shock 516.2 I
MIL 810D MIL 810E
Proc. Method Proc. Method
501.2 I, II 501.3 I, II 501.4
502.2 I, II 502.3 I, II 502.4-3
514.3 I 514.4 I 514.5
516.3 I 516.4 I 516.5
MIL 810F
Proc.
I, II
I, II
I
I
7
