1 1 1 1 - - - - 2 REMOTE CONTROL OPERATION

2 REMOTE CONTROL OPERATION 2 REMOTE CONTROL OPERATION 2 REMOTE CONTROL OPERATION
System control command System control command System control command System control command
▒ NOTE NOTE NOTE NOTE: All commands must be entered within 10 sec. of entering a password. It is possible to enter the password
▒ and command continuously.
Format of Command Format of Command Format of Command Format of Command
• Basic command code • Basic command code
• Basic command code • Basic command code
The Basic command code consists of a fixed 4-digit command code, preceded by a 1-digit Header Tone, and
followed by a 1-digit De-limiter Tone.
Header Tone Header Tone
Header Tone Header Tone
The Header tone is sent ahead of the command and indicates the start of the command. This tone is a fixed 1-
digit from 0—9, A—D, ∗(E), #(F) (programmed using CS-FR3000). The default setting is ∗(E).
De- - - - limiter Tone De limiter Tone
De De limiter Tone limiter Tone
The De-limiter is sent between commands and at the end of remote control codes. This tone indicates a space
between segments of the command as well as the end of the command. This tone is a fixed 1-digit from 0—9, A—
D, ∗(E), #(F) (programmed using CS-FR3000). The default setting is #(F).
Command Code Command Code Command Code Command Code
This field indicates the pre-programmed command or action to be executed. These codes are programmed to fixed This field indicates the pre-programmed command or action to be executed. These codes are programmed to fixed
4-digit codes in cloning software, and may include characters from 0—9, A—D, ∗ (E), #(F).
• Command code with sub code • Command code with sub code • Command code with sub code • Command code with sub code
The Command code with Sub code consists of basic command code and sub code (additionally required
information).
Sub Code Sub Code Sub Code Sub Code
This field is entered following the command code and indicates a memory channel number (for Memory CH
Select), an Autodial number (for Telephone Autodial), or a telephone number (for manual Tel dial commands). The
Sub Code will be a fixed 2-digit code for Memory CH Select and Telephone Autodial commands or may be up to
24-digits for Tel dial command.
• Command with password and sub code continuously • Command with password and sub code continuously
• Command with password and sub code continuously • Command with password and sub code continuously
This is the format required for entering commands for remote control operation.
Password Password
Password Password
The Password is a type of command code. The FR3000/FR4000 will enter the "System Control standby mode"
when it receives this command while in normal operating mode. This is a fixed 4-digit code that is programmed
using cloning software and may include digits from 0—9, A—D, ∗(E), #(F).
