Multi-Tone Function - Icom IC-FR3000 Series Sales Handbook

3-5
Multi- - - - tone function Multi Multi Multi tone function tone function tone function
The IC-FR3000/FR4000 allow relaying between
multiple groups with one repeater. (When group
separation is carried out with a continuous tone)
This feature can be used in both LMR and PMR mode.
• Optional 16 Tx/Rx continuous tones can be set for
each of the 32 channels.
• The Tx and RX tone can be set independently.
(CTCSS/DTCS) E.g. Rx (88.5 Hz) / Tx (223)
• The DTCS inverse code can be selected. (Normal /
Inverse)
Group A
C.Tone=88.5Hz
Multi Multi- - - - tone function (Programming example) Multi Multi tone function (Programming example) tone function (Programming example) tone function (Programming example)
Memory Ch. setting Memory Ch. setting
Memory Ch. setting Memory Ch. setting
• Set the C.Tone to "Multi".

Multi-tone Function

Operation Operation Operation Operation
• The continuous tone is set for each group.
• When Group A is using the repeater, the other groups
• When the Group A relay is finished, the other groups
Group B
C.Tone=023N
cannot use it.
can then use the repeater.
Multiple Tone setting Multiple Tone setting Multiple Tone setting Multiple Tone setting
• Select a Memory channel.
• Set an optional C.Tone for Tx/Rx respectively.
Group C
C.Tone=151.4Hz
33
