LASER 200
INTRODUCTION
Thank you for choosing the LASER 200 ARTF by SEAGULL MODELS. The LASER 200 was
designed with the intermediate/advanced sport flyer in mind. It is a semi scale airplane which is easy
to fly and quick to assemble. The airframe is conventionally built using balsa, plywood and veneer
to make it stronger than the average ARTF , yet the design allows the aeroplane to be kept light. You
will find that most of the work has been done for you already. The pushrods are pre-made to the
correct lengths, the motor mount has been fitted and the hinges are pre-installed and pinned for
security. Flying the LASER 200 is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your LASER 200 . Use the parts listing below to
identify all parts.
WARNING
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is
capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & RESPONSIBILITY.
If you are inexperienced with basic R/C flight we strongly recommend you contact your R/C supplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
procedures designed to help the new pilot on his way to successful R/C flight. They will also be able
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED
.91-1.20 2-stroke engine or
1.20-1.50 4-stroke engine.
Computer radio with six servos.
Glow plug to suit engine.
Propeller to suit engine.
Protective foam rubber for radio
system.
TOOLS & SUPPLIES NEEDED
Thick cyanoacrylate glue
30 minute epoxy
5 minute epoxy
Hand or electric drill
Assorted drill bits
Modelling knife
Straight edge ruler
2mm ball driver
Phillips head screwdriver
220 grit sandpaper
90° square or builder's triangle
Wire cutters
Masking tape & T-pins
Thread-lock
Paper towels
2

Instruction Manual

PARTS LISTING

FUSELAGE ASSEMBLY

(1) Fuselage.
(1) Canopy hatch.
WING ASSEMBLY
(1) Right wing half with pre-installed
aileron.
(1) Left wing half with pre-installed
aileron.
(1) Alumium wing dihedral brace.
Tail section assembly
(1) Vertical stabilizer with pre-
installed rudder.
(1) Horizontal stabilizer with pre-
installed elevator halves.
Some more parts.

HARDWARE PACK

COWLING
Landing gear.....
