BVM Bandit arf Assembly And Operation Instructions Manual page 63

2 4121A
2 4130
6 4273
2 MC5090
1 T110
2 W3345
1 W4321
2 W4337
1 K5300M-LC027
1 K5300M-LC028
1 K5300M-LC029
1 K5300M-LC031
K5300A-27 BA LINKAGE PACKAGE
Qty Needed Component ID
4 2884
7 4023
14 4093
14 4014B
3 PS-FS-0009
1 K5300M-LC033
1 K5300M-RC018
2 PM-RC-0001
K5300A-28 BA NOSE GEAR INSTALL
Qty Needed Component ID
1 2961
4 4133
2 4013A
2 4013B
1 4025
2 4183
BVM © 2009 K5300-Current_manual-090808.doc
Assembly & Operation Manual
#2 X 3/16 BUTTON HD SMS
#4 X 3/8 SMS
BOLT 10-32 X 3/4" SHCS
FLUSH WING SERVO ANGLES
1/2" X 30" VELCRO
3/8 X 1/2 X 1/2" MAPLE
MAPLE 1/4X1/2X1/2"
1-1/8 X 3/8 X 1/4 MAPLE""
BALTIC, 1/8", ECU TRAY
BALTIC, 1/8", STEERING TRAY
BALTIC, 1/8", FUEL TANK FORMER
BALTIC, 1/8", REAR FORMER
Component Description
4-40 X 2-1/2" FULL THREAD STUD
4-40 HEX NUT
SULLIVAN 4-40 CLEVIS
SULLIVAN KEEPER
STUD, SS, 4-40 3 " FULL THREAD
BALTIC,1/8", FLAP HORN LOCATOR
CF, .084, CONTROL HORNS AEFR
CF, .020, STAB TIP PROTECTOR
Component Description
1/16 x 10" WIRE
BOLT 4-40 X 5/16 PHIL
2/56 BALL THROTTLE-181 DUBRO
2-56 NUT
BALL LINK-NYLON
BVM 2-56 STEEL COUPLER
Page 60 12/2/2009
