BVM Bandit arf Assembly And Operation Instructions Manual page 61

K5300A-18 BA FLEX PLATES
Qty Needed Component ID
2 K5300M-RC019
2 K5300M-RC020
16 4029
K5300A-20 BA SERVO/EQP INSTALL PACKAGE
Qty Needed Component ID
8 4021
1 2865
8 4138
2 W3381
2 W3386
4 PS-SP-0009
K5300A-21 CANOPY/DECK PACKAGE
Qty Needed Component ID
1 1727
1 VF3006
1 LC3294
1 4074
1 8049
1 I7245
1 VF3918
K5300A-22 BA NOSE GEAR DOOR ATTACH PKG
Qty Needed Component ID
1 2961
1 2988
1 W3418
6 4051
1 4121
18 4121A
2 MC5045
1 LC3297
BVM © 2009 K5300-Current_manual-090808.doc
Assembly & Operation Manual
Component Description
CF, .084,Main Flexplate w/wash
CF, .084, Main Flexplate Dblr
BOLT 4-40 X 1/2 SHCS
Component Description
#4 FLAT WASHER
#2 X 7/16" SSSH bag of 75
BOLT 4-40 X 3/8 SHCS BLACK
3/8 X 5/8 X 3/4" MAPLE
3/8 X 1/2 X 3/4" MAPLE
TEES FOR SERVOS
Component Description
SUPER BANDIT DASHBOARD
BOBCAT COMP EJECTION SEAT
1/8 BALSA SEAT BACK
O-RING 1/16X1-1/4 BUNA
I BEAM PLASTIC 8"
S BANDIT CANOPY/DECK INSTRUCTI
SUPER BANDIT COCKPIT DECK
Component Description
1/16 x 10" WIRE
SPRING 1/8 x 1-1/4" EXT
1/4 X 3/8 X 5" MPL STICK
DUBRO HINGE & PINS
DOMED SMS 3/8 SOCKET
#2 X 3/16 BUTTON HD SMS
BVM STRUT DOOR ATTACHMENT
1/8 5PLY NG DOOR ACTUATOR
