The receiver is attached using sticky back Velcro.
Note the steering servo is installed from the underside of the steering servo tray.

NOSE GEAR DOOR

Carefully cut the front nose gear door from the rear nose gear door.
Use masking tape as a guide to prevent scratching the paint.
Make a hinge pin from .047" music wire bent in the shape of
an "L".
Remember to scuff all gluing surfaces, and glue the nose
gear door hinge in place with SLO-ZAP.
BVM © 2009 K5300-Current_manual-090808.doc
Assembly & Operation Manual
Make a notch 3/32" x 7/8" in the front end of the forward nose
gear door to accept the hinge pivot boss.
Page 37 12/2/2009
