NOTE: The red airlines connected to the brass micro air switch are reversed. Please refer to the Air
System Diagram for proper orientation.
MOUNTING THE NOSE GEAR
Mount the retract unit to the flex arms with 4-40 x 5/16" flat head screws.
FORWARD COMPARTMENT BOARD
BVM © 2009 K5300-Current_manual-090808.doc
Assembly & Operation Manual
Trim the plastic arm as shown and orient the air fittings for the
best possible routing as shown in the photo.
