Assembly & Operation Manual
Apply Aeropoxy generously to the pin base and wing root
and allow to cure.
Apply black ink to the point of the pin, install wing onto fuse
and allow the inked pin to mark the fuse side.
Drill a 1/8" hole at ink mark, then enlarge with a Perma-Grit
rotary tapered cone and round file. Adjust hole to allow the
wing leading edge to center on the fuse fairing.
Test fit the carbon fiber rectangle (with hole) onto the pin.
Apply Vaseline to the pin (wing off) , then use Slo-Zap to
tack glue the CF part to the inside fuse skin while assuring
that the wing leading edge is centered.
Remove the wing and apply Aeropoxy to the CF part to
secure it to the fuse.
