Mounting
1.11.2 Mounting the Cabinet
The cabinet has 5 moun7ting holes located at the rear. The upper
holes are of key-hole-type.
Consult the illustration above, and do the following:
Mark and drill all the holes according to the illustation.
Partly fasten the upper screws.
Hang the cabinet onto the upper screws.
Partly fasten the bottom screws.
Tighten all screws.
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Rev. J, 2011-12-06,
Autronica Fire and Security AS
